Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1810 x 768 x 930 mm | |
|---|---|---|
| Single seat width | 600 mm | |
| Seat height from floor | 450 mm | |
| Armrest height from floor | 620 mm | |
| Seat depth (front to back) | 480 mm | |
| Backrest height from seat surface | 480 mm | |
| Armrest width (horizontal) | 60 mm | |
| Support beam cross-section | 90 x 80 mm | |
| Leg spread (front to back per end) | 650 mm | |
| Leveling foot diameter | 50 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 45 kg | |
|---|---|---|
| Single seat static load capacity | 250 kg | |
| Seating durability cycle rating | 50000 cycles | |
| Recommended maximum simultaneous users | 3 | |
| Standard product service life | 10 years | |
| PU surface abrasion resistance | 100000 cycles | |
| Warranty period for structural components | 8 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and backrest padding | 30mm thick self-skinning high-density polyurethane, 60kg/m³ density, 40% rebound | |
|---|---|---|
| Internal seat/back frame | 1.2mm thick flat steel tube + 1.0mm welded steel plate skeleton, encased in PU | |
| Central support beam | 2.5mm thick powder-coated steel octagonal tube, silver-gray anti-rust finish | |
| End armrests | Die-cast ADC12 aluminum alloy, flash silver anti-oxidation spray finish | |
| Splayed end legs | Die-cast aluminum alloy, herringbone triangulated structure, silver coated finish | |
| Seat-to-beam connection brackets | 5.0mm thick cold-rolled stamped steel, welded and bolted fixed connection | |
| Floor leveling glides | Chrome-plated steel base with rubber anti-slip pad, adjustable height | |
| Seat divider supports | Die-cast aluminum alloy, silver coated, integrated between adjacent seat/back units | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seat configuration | Fixed non-reclining, non-folding 3 connected seats with no intermediate armrests | |
|---|---|---|
| Floor mounting capability | Compatible with expansion screw permanent floor fixation, plus adjustable leveling glides | |
| Surface cleaning compatibility | Waterproof, stain-resistant seamless PU surface, compatible with standard hospital-grade disinfectants | |
| Modular seat replacement | Individual seat/back units can be replaced independently without full bench disassembly | |
| Add-on accessory compatibility | Supports field installation of IV poles, fold-down writing tables, and USB charging ports | |
| Leveling adjustment | 15mm vertical adjustment range per floor glide to compensate for uneven floors | |
| Optional antibacterial coating | Available with medical-grade antibacterial PU surface for clinical waiting environments | |
| Outdoor upgrade option | Compatible with UV-stabilized PU and 304 stainless steel hardware for semi-outdoor use | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Hospital clinic waiting areas | Disinfectant-compatible PU surface, durable frame suitable for high daily patient traffic | |
|---|---|---|
| Airport/railway station waiting halls | High load capacity and abrasion resistance for continuous heavy public use | |
| Bank/government service hall waiting zones | Neat, durable fixed seating with easy cleaning for high-foot-traffic public offices | |
| Bus terminal passenger waiting areas | Stable triangulated leg structure and vandal-resistant construction for unsupervised public spaces | |
| Office building reception waiting areas | Professional dark green finish suitable for corporate visitor waiting zones | |
| School infirmary/campus public waiting areas | Stain-resistant surface and robust construction suitable for student public use | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Applicable for strength, durability and safety requirements for non-domestic public seating | |
|---|---|---|
| EN 13722:2004 | Applicable for furniture hardware performance requirements for fixed seat fasteners |
US and Canada office-furniture standards
| ANSI/BIFMA X5.11-2015 | Applicable for lounge and public seating large-user static load testing up to 159kg | |
|---|---|---|
| ANSI/BIFMA X5.4-2020 | Applicable for durability and stability testing of multi-seat public lounge seating |
Standards applicable to China-market projects
| GB/T 6461-2002 | Applicable for rating metal coating corrosion resistance on exposed aluminum and steel parts | |
|---|---|---|
| GB/T 3324-2017 | Applicable for general technical requirements of metal furniture structural safety | |
| GB/T 10357.3-2013 | Applicable for mechanical performance testing of seating furniture strength and durability | |
| Metal finish salt spray resistance grade | 10 |
This product must meet the following technical requirements: 1. GB/T 6461-2002: Applicable for rating metal coating corrosion resistance on exposed aluminum and steel parts; 2. GB/T 3324-2017: Applicable for general technical requirements of metal furniture structural safety; 3. GB/T 10357.3-2013: Applicable for mechanical performance testing of seating furniture strength and durability; 4. Metal finish salt spray resistance grade: 10; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
