Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2250 x 720 x 1100 mm | |
|---|---|---|
| Single seat width | 750 mm | |
| Seat height from floor | 450 mm | |
| Seat depth | 500 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest height (seat to top of headrest) | 850 mm | |
| Headrest dimensions | 300 x 180 x 80 mm | |
| Armrest height above seat | 220 mm | |
| Armrest width | 120 mm | |
| IV pole adjustable height above floor | 1800 mm | |
| IV pole tube diameter | 25 mm | |
| Support leg spread (end to end) | 680 mm | |
| Adjustable leveling foot diameter | 50 mm | |
| Under-seat perforated support panel thickness | 1.5 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm |
Net weight / load capacity / users / durability
| Weight capacity per seat | 200 kg | |
|---|---|---|
| Total chair net weight | 85 kg | |
| Backrest recline angle range | 160 degrees | |
| Foam density (seat and back) | 45 kg/m³ | |
| Foam rebound rate | 60% | |
| PU upholstery abrasion resistance | 50000 cycles | |
| IV pole static load capacity per hook | 5 kg | |
| Seam stitch pitch | 8 stitches per inch | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main support frame | 1.5mm thick chrome-plated cold-rolled steel tube | |
|---|---|---|
| Seat and back support panel | Perforated cold-rolled steel plate with chrome finish | |
| Upholstery covering | Medical-grade antibacterial teal PU leather | |
| Cushion padding | High-density molded polyurethane foam | |
| Headrest padding | 80mm thick high-resilience polyurethane foam | |
| Armrests | Solid dark brown wood with polished sealed finish | |
| IV poles | 25mm diameter polished stainless steel tube | |
| IV pole hooks | Chrome-plated steel dual hooks per pole | |
| Recline mechanism | Powder-coated steel manual recline linkage with lock | |
| Leveling feet | Non-marking rubber with adjustable steel threaded stud | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Manual backrest recline | Side-activated lever locks backrest at positions up to 160 degrees | |
|---|---|---|
| IV pole height adjustment | Telescoping stainless steel pole locks at heights from 1200mm to 1800mm | |
| Dual IV hook per position | Two hooks per pole support separate infusion bags and drainage pouches | |
| Floor leveling adjustment | Threaded rubber feet adjust to compensate for uneven clinic flooring | |
| Disinfectant-compatible surfaces | PU upholstery and metal frames tolerate alcohol and chlorine disinfection | |
| Beam-mounted tandem seating | Three positions share a continuous steel support beam for structural rigidity | |
| Fixed-position armrests | Curved wood armrests provide stable elbow support during extended infusions | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Assembly note | Semi-knocked-down design requires attaching IV poles, armrests and feet | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Hospital outpatient infusion rooms | Tandem layout maximizes patient capacity with dedicated IV support for clinical use | |
|---|---|---|
| Community clinic waiting areas | Durable construction and easy-to-disinfect surfaces suit high-traffic public medical spaces | |
| Emergency department observation zones | Reclining function supports extended patient stays during IV treatment | |
| Vaccination and injection clinics | Integrated poles can hold supplies, stable seating suitable for short procedures | |
| Rural health center treatment areas | Stainless steel components resist corrosion in high-moisture clinical environments | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Strength, durability and stability requirements for non-domestic seating | |
|---|---|---|
| EN 1022:2018 | Seating stability test standard for public area furniture |
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable to frame durability and stability | |
|---|---|---|
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to wood armrest components | |
| GB/T 16799-2008 | General technical requirements for polyurethane leather, applicable to PU upholstery material |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable to frame durability and stability; 2. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to wood armrest components; 3. GB/T 16799-2008: General technical requirements for polyurethane leather, applicable to PU upholstery material; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
