PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	1780 × 680 × 800 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Seating capacity	3 adults
Total unit weight	28 kg
Static load per seat	150 kg
Total static load rating	450 kg
Durability cycle rating	100000 use cycles
Recommended warranty period	3 years
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%
Back Foam Density Reference	38 kg/m³
Upholstery Thickness / Abrasion Reference	1.4 mm / 50000 cycles
Five-star Base Static Load Reference	Acceptance target ≥120 kg; chair reference load 150 kg

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Main support beam	2.0mm thick chrome-plated cold-rolled steel
Seat support frame	1.5mm thick powder-coated cast aluminum alloy
Seat padding	30mm thick high-density polyurethane foam
Backrest panel	25mm thick high-density polyurethane over steel backing
Upholstery surface	1.0mm thick polyurethane (PU) leather, abrasion resistance 50000 Martindale cycles
Armrests	1.8mm thick polished cast aluminum alloy
Support legs	2.5mm thick chrome-plated steel tripod legs
Floor glides	Adjustable rubber-padded steel leveling glides
Frame finish	Satin silver chrome plating on steel components
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seat configuration	Three connected fixed seats on a single continuous steel beam
Armrest placement	Curved armrests installed only on the two outermost seat positions
Leveling adjustment	Adjustable glides at each leg to compensate for uneven floor surfaces
Floor mounting option	Pre-drilled glide bases allow permanent bolting to hard floor surfaces
Cleaning access	Open under-seat clearance allows full access for floor mopping and debris removal
Back support design	Fixed 100-degree tilted backrest for upright short-duration waiting
Surface finish property	Non-porous PU upholstery allows wipe-down cleaning with standard disinfectants
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Hospital waiting areas	Suitable for clinic lobbies and patient waiting zones due to durable easy-clean surfaces
Transportation hubs	Ideal for airport, bus station and railway station waiting zones with high foot traffic
Government service halls	Appropriate for public service offices, bank lobbies and visa centers
Office reception areas	Useable in corporate lobby waiting zones for visitors
School administration areas	Suitable for school office entrances and student affairs waiting spaces
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

Applicable public seating safety standard	EN 16139:2013
Applicable upholstery fire standard	EN 1021:2014
Applicable surface emission standard	EN 16516:2017

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

Applicable commercial seating standard	ANSI/BIFMA X2021
Applicable stability test standard	ANSI/BIFMA X5.4 Clause 5

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

Applicable standard for mechanical safety	GB/T 3326
Applicable surface durability standard	GB/T 4893.8
Applicable structural strength standard	GB/T 10357.3

Standardized tender description text

This product must meet the following technical requirements:
1. Applicable standard for mechanical safety: GB/T 3326;
2. Applicable surface durability standard: GB/T 4893.8;
3. Applicable structural strength standard: GB/T 10357.3;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · WAIT-CHR-3S-RED-PU

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · WAIT-CHR-3S-RED-PU

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · WAIT-CHR-3S-RED-PUOpen Export Tool

Quick Actions

Post an RFQ

Product Description

This 3-seat public waiting chair features a streamlined beam seating layout with three connected fixed seats anchored to a single continuous steel support beam. Curved polished cast aluminum armrests are positioned only at the two outermost seats, leaving the middle seating positions armless to maximize usable space for users. The chair has a polished satin silver chrome finish on all steel structural components, paired with vibrant red polyurethane leather upholstery that creates a clean, recognizable visual profile suited to high-traffic public environments. Its fixed backrests are set at a 100-degree tilt to support upright, short-duration waiting, with a dedicated lumbar support zone to maintain comfortable posture during brief stays.
The chair’s core structure is built from heavy-gauge metal components: the main support beam uses chrome-plated cold-rolled steel, seat support frames are made from powder-coated cast aluminum alloy, and tripod support legs are formed from thick chrome-plated steel. Each seat and backrest is padded with high-density polyurethane foam set over rigid steel backing, wrapped in non-porous 1.0mm thick PU leather that resists abrasion. Adjustable rubber-padded steel glides fitted to each leg can be calibrated to compensate for uneven floor surfaces, and pre-drilled glide bases allow permanent bolting to hard flooring for added stability where required.
Designed for practical high-use operation, the chair supports three adult users, with open under-seat clearance that allows unobstructed access for mopping and debris removal. The non-porous upholstery can be fully wiped down with standard disinfectants to support routine hygiene maintenance.
This seating solution is well suited to a wide range of commercial and public spaces, including hospital clinic lobbies and patient waiting zones, high-foot-traffic transportation hubs such as airports, bus and railway stations, government service halls, bank lobbies and visa centers, corporate office reception waiting areas, and school administration and student affairs waiting spaces.
When planning procurement, note that each unit ships across two cartons, requires a standard assembly window for on-site setup, and comes with a recommended 3-year warranty. Buyers should account for floor preparation needs for either free-standing leveled placement or permanent bolted installation, and can reference standard 20-foot container load capacities to plan bulk shipping efficiently.

3-Seat Metal Frame Public Waiting Chair with Red Upholstery Specifications
