Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 680 x 800 mm | |
|---|---|---|
| Seat height | 430 mm | |
| Single seat width | 580 mm | |
| Seat depth | 480 mm | |
| Backrest height | 420 mm | |
| Armrest height | 660 mm | |
| Leg spread width | 620 mm | |
| Floor clearance | 180 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 28 kg | |
|---|---|---|
| Total static load capacity | 480 kg | |
| Seat pad foam thickness | 40 mm | |
| Foam density | 35 kg/m³ | |
| Seam stitch pitch | 8 stitches per 30mm | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Leg static load rating per leg | 180 kg | |
| Standard available color options | 3 | |
| Foam rebound rate | 45% | |
| Available color options | 3 |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame structure | 1.5mm thick cold-rolled steel tube with silver powder-coated finish | |
|---|---|---|
| Seat support beams | 2mm thick rectangular steel cross-bars under each seat | |
| Seat upholstery | 1.2mm thick black polyurethane (PU) leather | |
| Backrest upholstery | 1.2mm thick black polyurethane (PU) leather | |
| Seat padding | High resilience polyurethane foam | |
| Backrest padding | High resilience polyurethane foam | |
| Armrests | 1.8mm thick bent steel tube with silver powder-coated finish | |
| Foot glides | Nylon and rubber anti-slip adjustable glides | |
| Frame connection hardware | Zinc-plated steel bolts and brackets | |
| Main support frame | 1.5mm thick cold-rolled steel tube with silver powder-coated finish | |
| Leg assemblies | 2.0mm thick cold-rolled steel Y-shaped legs with silver powder-coated finish | |
| Seat support crossbars | 2.0mm thick rectangular steel cross-bars under each seat |
Adjustment / rotation / tilt / mobility / storage features
| Seating capacity | 3 individual users | |
|---|---|---|
| Fixed position construction | Fully welded and bolted fixed structure | |
| Integrated end armrests | Two curved armrests at outer ends of the bench | |
| Raised under-seat clearance | 180mm open space under seats | |
| Spill-resistant upholstery surface | Non-porous PU upholstery on seat and back | |
| Floor anchoring compatibility | Pre-drilled holes in foot glide bases | |
| Separated seat gaps | 20mm gaps between adjacent seat units | |
| Fixed rigid construction | Fully welded and bolted permanent structure | |
| End armrest supports | Two curved loop armrests at outer bench ends | |
| Under-seat cleaning clearance | 180mm open unobstructed space under seats | |
| Spill-resistant upholstery | Non-porous PU surface on seat and back pads | |
| Inter-seat ventilation gaps | 20mm gaps between adjacent seat and back units |
Verified carton / gross weight / assembly / loading data
| Number of shipping cartons | 1 | |
|---|---|---|
| Shipping carton dimensions | 1850 x 730 x 280 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit | 0.38 CBM | |
| Assembly time per unit | 30 minutes | |
| 20ft GP container loading quantity | 140 units | |
| 40ft HQ container loading quantity | 350 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| Hospital outpatient waiting areas | Durable, easy-to-clean construction meets high-traffic clinic requirements, and fixed structure prevents rearrangement in medical facility zones | |
|---|---|---|
| Office building reception and lobby areas | Neutral silver and black finish matches professional corporate interiors, provides temporary seating for visitors and guests | |
| Public transport station waiting halls | High static load capacity and abrasion-resistant upholstery support constant use by travelers in bus, train or airport terminals | |
| Bank and government service hall waiting zones | Structural stability and clear seating boundaries support orderly queuing and waiting for service counter access | |
| School administrative and public common areas | Robust metal frame resists damage from heavy student use, while non-porous upholstery simplifies daily janitorial cleaning | |
| Warranty for commercial use | 3 years | |
| Office building reception lobbies | Neutral silver and black finish matches professional corporate interiors, provides temporary seating for visitors and meeting attendees | |
| Bank and government service halls | Defined seating positions and stable anti-tip construction support orderly queuing and waiting for service counter access |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety - Non-domestic seating | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability | |
| EN 13722:2004 | Furniture - Upholstered furniture - Determination of upholstery fabric durability |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture | |
|---|---|---|
| GB 18584-2001 | Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | |
| GB/T 24821-2009 | Public seating for airport and railway station |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture; 2. GB 18584-2001: Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture; 3. GB/T 24821-2009: Public seating for airport and railway station; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
