Automatic mm / inch conversion · Core engineering specifications
| overall dimensions | 1800 x 680 x 800 mm | |
|---|---|---|
| seat height | 430 mm | |
| seat depth per position | 480 mm | |
| seat width per position | 550 mm | |
| backrest height | 400 mm | |
| armrest height above seat | 200 mm | |
| leg spread width | 1650 mm | |
| leg base depth | 650 mm | |
| seat pan material thickness | 8 mm | |
| frame beam cross-section | 60 x 30 mm | |
| floor glide diameter | 50 mm | |
| main support beam cross-section | 60 x 30 mm | |
| under-seat clearance | 320 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm |
Net weight / load capacity / users / durability
| net product weight | 28 kg | |
|---|---|---|
| static load per seat position | 150 kg | |
| total static load capacity | 450 kg | |
| recommended occupancy | 3 adults | |
| seamless panel impact resistance | 10 J | |
| floor glide load rating per foot | 120 kg | |
| warranty period for structural frame | 5 years | |
| structural frame warranty period | 5 years | |
| PU panel surface abrasion resistance | 20000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| seat and back panels | Integral self-skinning rigid polyurethane (PU) with matte orange finish | |
|---|---|---|
| main support beam | Die-cast aluminum alloy with powder-coated matte silver finish | |
| end armrests | Polished die-cast aluminum alloy | |
| side leg assemblies | Polished die-cast aluminum alloy curved leg frames | |
| floor contact glides | Non-marking thermoplastic rubber (TPR) adjustable feet | |
| connecting hardware | 304 stainless steel bolts and fasteners | |
| panel surface finish | Textured matte anti-scratch PU coating | |
| seat-back joint reinforcement | Embedded 2mm thick galvanized steel mounting plates | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| fixed ergonomic contouring | Seat and back panels are pre-formed with 105 degree torso angle to support upright seated posture without adjustment | |
|---|---|---|
| permanent 3-position seat division | Integrated curved dividers between seats prevent cross-position sliding and define individual seating space | |
| fixed armrest support at ends | Two polished aluminum armrests mounted only at outermost seating positions to aid standing and sitting | |
| non-adjustable floor stabilization | Four adjustable TPR glides compensate for up to 15 mm of uneven floor height without requiring permanent floor anchoring | |
| easy-clean seamless surface | One-piece PU seat and back panels have no fabric gaps or seams to trap dirt, supporting wipe-down disinfection for high-traffic environments | |
| structural anti-tip design | Curved splayed leg layout extends support footprint outside the seat perimeter to prevent tipping when occupants lean on armrests | |
| corrosion-resistant construction | All exposed metal components use aluminum or stainless steel materials to resist rust and degradation from daily cleaning and high humidity use | |
| fixed end armrest support | Two polished aluminum armrests mounted only at outermost seating positions to aid standing and sitting transfers | |
| non-permanent floor stabilization | Four adjustable TPR glides compensate for up to 15 mm of uneven floor height without requiring drilling or permanent floor anchoring | |
| Recline Angle / Lock Reference | 125° with 3 suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| number of shipping cartons | 1 carton | |
|---|---|---|
| shipping carton dimensions | 1850 x 720 x 350 mm | |
| gross shipping weight | 32 kg | |
| shipping volume per unit | 0.47 CBM | |
| required assembly time | 30 minutes | |
| 20ft GP container load quantity | 56 units | |
| 40ft HQ container load quantity | 140 units | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm |
Recommended spaces / users / usage modes
| airport terminal waiting areas | Durable construction and easy-clean surfaces support high-frequency daily use by large volumes of passengers with minimal maintenance | |
|---|---|---|
| hospital and clinic waiting zones | Disinfectant-resistant seamless PU surfaces allow frequent sanitization to meet healthcare facility hygiene requirements | |
| railway and bus station concourses | Rigid aluminum frame resists heavy impact and constant use in high-turnover public transit environments | |
| government service hall queuing areas | Fixed individual seating positions maintain orderly queue spacing while providing comfortable short-term waiting seating | |
| bank and office reception waiting areas | Neutral orange and silver finish complements commercial interior design while providing durable visitor seating | |
| school and public library common areas | Stable anti-tip design provides safe seating for high-traffic student and visitor use without risk of collapse | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139 | 2013 Furniture - Strength, durability and stability - Non-domestic seating: Applicable for public non-domestic seating performance and stability acceptance criteria | |
|---|---|---|
| EN 13722 | 2004 Furniture - Assessment of surface resistance to cold liquids: Applicable for verification of PU panel resistance to cleaning agents and common public space spills | |
| EN 1022 | 2018 Furniture - Seating - Determination of stability: Applicable for anti-tip performance verification of free-standing public bench seating |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 General technical requirements for furniture | Applicable for general structural performance and appearance quality acceptance of metal-frame public seating | |
|---|---|---|
| GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture | Applicable for volatile organic compound emission testing of non-metal seating components | |
| GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools | Applicable for static load and fatigue performance verification of seating structures |
This product must meet the following technical requirements: 1. GB/T 3324-2017 General technical requirements for furniture: Applicable for general structural performance and appearance quality acceptance of metal-frame public seating; 2. GB 18584-2001 Indoor decorating and refurbishing materials - Limit of harmful substances of wood based furniture: Applicable for volatile organic compound emission testing of non-metal seating components; 3. GB/T 10357.3-2013 Test of mechanical properties of furniture - Strength and durability of chairs and stools: Applicable for static load and fatigue performance verification of seating structures; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
