Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 680 x 800 mm | |
|---|---|---|
| Seat height from floor | 450 mm | |
| Single seat width | 560 mm | |
| Seat depth | 480 mm | |
| Backrest total height | 400 mm | |
| Armrest height from seat surface | 220 mm | |
| Leg spread width (end to end) | 1720 mm | |
| Leg spread depth (front to rear) | 620 mm | |
| Padded upper back height | 280 mm | |
| Mesh lower back height | 120 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net product weight | 28 kg | |
|---|---|---|
| Static load per seat | 150 kg | |
| Total bench static load capacity | 450 kg | |
| Recommended maximum user weight per seat | 120 kg | |
| PU upholstery abrasion resistance | 50000 cycles | |
| Frame static load test rating | 1200 kg | |
| Surface corrosion resistance | 48 hours | |
| Seat impact resistance | 10000 cycles | |
| Backrest cyclic load durability | 100000 cycles | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Frame main structure | 1.5 mm thick cold-rolled steel tube with polished chrome plating | |
|---|---|---|
| Lower back support panel | 1.0 mm thick perforated diamond-mesh steel with chrome finish | |
| Seat padding | 30 mm thick high-density polyurethane foam, density 45 kg/m³ | |
| Upper back padding | 20 mm thick high-density polyurethane foam, density 40 kg/m³ | |
| Seat and back upholstery | 1.2 mm thick teal matte polyurethane (PU) leather | |
| Armrests | 1.2 mm thick bent chrome-plated steel tube, polished finish | |
| Support legs | 2.0 mm thick bent chrome-plated steel tube with cross-braced connection | |
| Leveling feet | 30 mm diameter non-slip rubber-padded adjustable steel feet | |
| Seat divider trim | Polished chrome steel edge trim along seat and back panel edges | |
| Under-seat support beam | 2.0 mm thick rectangular cold-rolled steel tube with black powder-coated side trim | |
| Backrest mounting brackets | 2.5 mm thick stamped chrome-plated steel brackets connecting back panels to main beam | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board |
Adjustment / rotation / tilt / mobility / storage features
| Seat configuration | 3 individual contoured seat positions with fixed upright backrests | |
|---|---|---|
| Armrest placement | 2 outer armrests at left and right ends of the bench, no intermediate armrests between seats | |
| Floor leveling adjustment | Adjustable rubber feet at each leg, allowing 15 mm height adjustment to compensate for uneven floor surfaces | |
| Ventilation design | Perforated mesh lower back panel to allow air circulation during extended waiting periods | |
| Surface cleaning compatibility | Smooth PU upholstery and chrome frame compatible with standard hospital-grade disinfectant cleaners | |
| Mounting option | Pre-drilled foot plates to allow permanent floor anchoring for high-security or high-traffic installations | |
| Seat contour design | Contoured waterfall front seat edge to reduce leg pressure during extended sitting | |
| Anti-tip stability | 620mm front-to-rear leg spread provides 12-degree backward tip resistance per standard stability testing requirements | |
| Backrest recline angle from vertical | 10 degrees | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel |
Verified carton / gross weight / assembly / loading data
| Number of shipping packages | 1 unit | |
|---|---|---|
| Shipping carton dimensions | 1850 x 720 x 280 mm | |
| Gross shipping weight | 32 kg | |
| Shipping volume per unit | 0.37 CBM | |
| assembly time per unit | 30 minutes | |
| 20ft GP container loading capacity | 68 units | |
| 40ft HQ container loading capacity | 170 units | |
| Packaging material | 5-layer corrugated carton with EPS foam edge protection and PE plastic wrapping | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set |
Recommended spaces / users / usage modes
| Hospital and clinic waiting areas | Ideal for patient and visitor waiting zones, with disinfectant-compatible surfaces and durable construction suitable for continuous high-volume use | |
|---|---|---|
| Public transport waiting areas | Suitable for airport, railway station and bus terminal waiting halls, with high abrasion resistance and stable frame for heavy daily traffic | |
| Bank and government service hall waiting zones | Appropriate for public service counter waiting areas, providing fixed orderly seating with easy maintenance | |
| Office building reception and lobby areas | Can be used in office lobby visitor waiting zones, with neutral metallic finish matching modern commercial interior design | |
| School and public institution common areas | Suitable for campus waiting, registration and public event waiting areas, with robust construction resistant to rough daily use | |
| Retail and service outlet waiting zones | Appropriate for pharmacy, telecom store and auto service center customer waiting areas, with easy-to-clean surfaces and compact size for small public spaces | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 16139:2013 | Furniture - Strength, durability and safety requirements for non-domestic seating, applicable for non-domestic public space performance verification | |
|---|---|---|
| EN 1022:2018 | Furniture - Seating - Determination of stability, applicable for tipping resistance verification of the gang bench | |
| EN 14465:2003 | Furniture - Upholstered furniture abrasion resistance of cover fabrics, applicable for PU upholstery wear performance verification |
US and Canada office-furniture standards
| North America procurement and testing reference | ANSI/BIFMA X5.4 Public and Lounge Seating |
|---|
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for metal furniture, applicable for structural stability and finish quality verification of this steel waiting bench | |
|---|---|---|
| GB/T 10357.3-2013 | Furniture mechanical performance test for seating: chair and stool strength and durability, applicable for static load and fatigue testing of this bench | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances in wooden furniture, applicable for volatile organic compound emission verification of PU upholstery and foam components | |
| GB/T 10357.2-2013 | Furniture mechanical performance test for seating: chair and stool stability, applicable for anti-tip performance verification of the bench |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for metal furniture, applicable for structural stability and finish quality verification of this steel waiting bench; 2. GB/T 10357.3-2013: Furniture mechanical performance test for seating: chair and stool strength and durability, applicable for static load and fatigue testing of this bench; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances in wooden furniture, applicable for volatile organic compound emission verification of PU upholstery and foam components; 4. GB/T 10357.2-2013: Furniture mechanical performance test for seating: chair and stool stability, applicable for anti-tip performance verification of the bench; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
