PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	610 × 610 × 1020 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Recommended user weight capacity	120 kg
Net weight	12.5 kg
Static seat loading reference	600 kg downward for 1 hour
Caster rolling durability	100000 cycles
Gas-lift cycling durability	100000 height cycles
Backrest cyclic durability	100000 recline cycles
Seat foam density	45 kg/m3 high-resilience polyurethane
Foam resilience	40 percent ball rebound
Fabric abrasion resistance	50000 Martindale cycles
Seating capacity	1 person

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Backrest support surface	Black flexible mesh with woven zigzag pattern, stretched in a framed polymer back carrier
Seat upholstery	Orange woven fabric over molded foam cushion with black lower edge trim
Seat cushion core	70 mm molded polyurethane foam, 45 kg/m3 density target
Armrest assembly	Black rigid polymer T-arms with rectangular pads and vertical support posts
Under-seat mechanism	Black steel tilt mechanism with polymer cover and side adjustment lever
Lift and base system	Black painted steel five-star base with 50 mm telescoping gas lift

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Height adjustment	Pneumatic seat-height lift with side paddle lever, providing 100 mm travel from 440 to 540 mm
Recline and lock	Center-tilt mechanism allowing 17-degree back movement from 95 to 112 degrees, with lockable upright position
Tension control	Rear rotary knob adjusts backward tilt resistance for users up to 120 kg
Mobility	Five-point caster base provides omnidirectional movement on level hard floors or low-pile carpet

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Gross weight per carton	14 kg
Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Open-plan office workstation	Suited to desk-based staff using a 720 to 760 mm office desk because the 440 to 540 mm seat height supports standard work surfaces.
Meeting or study area	Appropriate for hot desks, training rooms and home offices where one-person swivel seating and easy rolling access are required.

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

No standards data is available for this market.

STANDARD S2

North America Purchasing & Inspection Reference * ANSI/BIFMA Standards

US and Canada office-furniture standards

North America procurement and testing reference	Recommended references: ANSI/BIFMA X5.1

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

No standards data is available for this market.

Standardized tender description text

This product must meet the following technical requirements:
1. Technical standards and test reports must be supplied during tender or purchase confirmation;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · TSK-MESH-OR-FA-01

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · TSK-MESH-OR-FA-01

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · TSK-MESH-OR-FA-01Open Export Tool

Quick Actions

Post an RFQ

Product Description

The Mesh Back Swivel Task Chair with Orange Fabric Seat and Fixed Arms is an unbranded office chair designed for everyday desk use. Model TSK-MESH-OR-FA-01 combines a black flexible mesh back with a contrasting orange woven fabric seat, giving it a functional, contemporary appearance suited to active workspaces. The back mesh uses a woven zigzag pattern stretched within a framed polymer carrier, while the seat is finished with orange fabric over a molded cushion and black lower-edge trim. Black polymer armrests, shell components, mechanism covers, and a painted steel five-star base complete the visual layout and keep the chair consistent with standard office interiors. Its fixed T-shaped arms include rectangular pads and vertical support posts, with a clear width between armrests of 540 mm. Construction centers on a cushioned seat and structured back support. The seat cushion features a 70 mm molded polyurethane foam core with a 45 kg/m3 high-resilience foam target, while the finished cushion thickness is 90 mm. The backrest provides 70 mm of padding thickness and includes a lumbar support zone height of 240 mm. Under the seat is a black steel tilt mechanism with a polymer cover and side adjustment lever. The chair is mounted on a black painted steel five-star base, a 50 mm telescoping gas-lift column, and twin-wheel casters for movement. Practical functions support routine office tasks. A pneumatic seat-height lift operated by a side paddle lever provides 100 mm of travel, adjusting seat height from 440 to 540 mm. The center-tilt mechanism allows 17 degrees of back movement from 95 to 112 degrees and includes a lockable upright position. A rear rotary knob adjusts backward tilt resistance for users up to 120 kg. The five-point caster base enables omnidirectional movement on level hard floors or low-pile carpet, and the swivel design supports easy turning and access around a workstation. This chair is appropriate for open-plan office workstations, particularly for desk-based staff using standard office desks. It is also suitable for hot desks, training rooms, meeting or study areas, and home offices where single-person swivel seating and rolling mobility are needed. The orange seat adds a visual accent while the black frame and base remain broadly compatible with commercial furniture schemes. For procurement planning, note the recommended user weight capacity of 120 kg and the chair net weight of 12.5 kg. Reference durability values include 100000 caster rolling cycles, 100000 gas-lift height cycles, and 100000 backrest recline cycles, along with a static seat loading reference of 600 kg downward for one hour. Each set is supplied in two cartons, with a packaged gross weight of 23 kg per set and a reference assembly time of 40 minutes per set. Buyers should allocate receiving, storage, and assembly time accordingly and confirm floor surface compatibility, fixed-arm clearance, and seat-height suitability for the intended desks and users.

Mesh Back Swivel Task Chair with Orange Fabric Seat and Fixed Arms Specifications
