基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源:工厂资料结构化字段,最终以实测值为准
| 产品外部尺寸(宽 × 深 × 高) | 800 × 800 × 510 mm | |
|---|---|---|
| Overall assembled dimensions | 800 x 800 x 510 mm | |
| Tabletop thickness | 12 mm | |
| Corner radius of tabletop | 50 mm | |
| Metal leg cross-section width | 40 mm | |
| Metal frame wall thickness | 1.5 mm | |
| Under-table floor clearance | 420 mm | |
| Base footprint outer span | 720 x 720 mm | |
| Center junction cross-brace height | 80 mm | |
| Edge overhang from leg to tabletop edge | 40 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源:产品性能数据,采购前请核对具体测试口径
| Distributed static tabletop load capacity | 100 kg | |
|---|---|---|
| Product net weight | 22 kg | |
| Surface abrasion resistance | 2000 cycles | |
| Frame rust resistance rating | Grade 1 for indoor use | |
| Recommended number of users | 4 people | |
| Surface water repellency rating | No penetration for 24 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源:以工厂材质清单与验货报告为准
| Tabletop surface | White base with grey marble veining, sintered stone or high-pressure laminate | |
|---|---|---|
| Tabletop edge banding | Matching matte white PVC/ABS edge trim | |
| Support frame base | Matte black powder-coated carbon steel, welded one-piece geometric structure | |
| Central cross-brace | Same powder-coated steel as legs, box-section welded joint | |
| Floor contact feet | Injection-molded black non-slip plastic glides | |
| Frame surface finish | 80 micron matte black powder coat | |
| Tabletop core substrate | High-density MDF or particleboard core under stone/laminate face | |
| Fasteners | Zinc-plated steel hex bolts and cam locks for tabletop-to-frame attachment | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源:功能配置参数,以供应商正式规格为准
| Assembly requirement | Knock-down assembly required, attaching top to pre-welded base with included hardware | |
|---|---|---|
| Surface cleaning function | Non-porous sealed top supports wipe-clean with damp cloth, no sealing required | |
| Floor protection function | Plastic glides at leg bases prevent scuffing on hard floors and carpet | |
| Structural stability function | Interlocking geometric base distributes weight evenly, no tipping under offset loads | |
| Adjustment function | Optional threaded glides allow 5mm height adjustment for uneven floors | |
| Usage position function | Fixed low height aligned to standard sofa seat height for beverage/snack placement | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源:外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源:依据产品结构与品类整理的推荐应用场景
| Primary application space | Residential living room center placement in front of sofas and sectionals | |
|---|---|---|
| Secondary application space | Reception lounge areas, small office waiting rooms, apartment balcony lounge zones | |
| Target user group | Urban residents, renters, modern minimalist interior design projects | |
| Recommended pairing | Pair with 3-seat sofas, modular sectionals, or fabric/leather lounge chairs seating 4people | |
| Surface usage suitability | Placement of beverages, books, decorative items, remote controls, and small table lamps | |
| Flooring compatibility | Suitable for carpet, hardwood, tile, and vinyl flooring with installed floor glides |
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| Furniture safety for domestic use | EN 12521:2015 | |
|---|---|---|
| Surface formaldehyde emission | EN 13986:2004+A1:2015 E1 grade | |
| Powder coating performance | EN 13438:2020 |
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| Tabletop formaldehyde emission | GB/T 39600E0 grade | |
|---|---|---|
| Furniture mechanical stability | GB/T 10357.1 | |
| Metal coating adhesion | GB/T 9286Grade 1 | |
| Furniture surface wear resistance | GB/T 4893.8 |
本产品须满足以下技术参数要求: 1. Tabletop formaldehyde emission:GB/T 39600E0 grade; 2. Furniture mechanical stability:GB/T 10357.1; 3. Metal coating adhesion:GB/T 9286Grade 1; 4. Furniture surface wear resistance:GB/T 4893.8; 最终交付参数、检测报告和验收标准以双方采购合同为准。
