| 纠错时间 | 修改字段 | 原参数 | 修改后参数 | 说明 / 状态 |
|---|---|---|---|---|
暂无参数纠错记录，发现错误可点击行末旗标提交 | ||||
mm / 英寸自动双单位换算 · 工程采购基础规格
| Overall dimensions | 600 x 457 x 680 mm | |
|---|---|---|
| Top surface thickness | 15 mm | |
| Drawer internal dimensions | 316 x 234 x 100 mm | |
| Leg height (floor to body bottom) | 150 mm | |
| Leg diameter at top connection | 34 mm | |
| Leg diameter at floor contact | 24 mm | |
| Body height (excluding legs) | 445 mm | |
| Floor clearance under drawer front | 150 mm | |
| Center support leg projection below body | 130 mm | |
| Recessed half-moon pull cutout width | 80 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
净重 / 最大承重 / 适用人数 / 耐久性能
| Top surface static load capacity | 18 kg | |
|---|---|---|
| Unit net weight | 22 kg | |
| Recommended maximum user weight for edge seating | 50 kg | |
| Drawer slide cycle durability | 20000 open/close cycles | |
| Surface scratch resistance | Class 2 (1.5N abrasion) | |
| Surface water resistance | Resists 24-hour cold liquid ring staining | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg | |
| Recommended Procurement Warranty | Frame 10 years; hardware 5 years; upholstery 2 years |
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
| Main carcass panels | 15 mm engineered particleboard with light oak melamine finish, fluted/ribbed side texture | |
|---|---|---|
| Drawer front panel | 12 mm MDF with matte white UV-cured foil finish, recessed half-moon cutout pull | |
| Legs (4 splayed + 1 center support) | Solid pine wood with clear lacquer finish, tapered cylindrical profile | |
| Drawer side/back panels | 12 mm engineered MDF with smooth melamine interior finish | |
| Drawer glide hardware | Cold-rolled steel 3/4 extension telescopic slides with zinc plating | |
| Edge banding | 0.4 mm PVC edge banding matching light oak and white panel colors | |
| Leg foot pads | Non-marking black rubber pads bonded to leg bases to protect hard flooring | |
| Joinery hardware | Zinc-plated steel confirmat screws and cam-lock connectors for RTA assembly | |
| Back panel | 3 mm hardboard with light oak finish, fitted into recessed carcass grooves | |
| Slat Thickness | 15 mm bent plywood or solid timber | |
| Primary Connector Specification | Reference M8-M10 bolts with at least 2 fixing points per corner | |
| Reference Finish / Color Count | Recommended 6timber/upholstery options |
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
| Drawer operation | Horizontal pull-out 3/4 extension via recessed half-moon cutout, no exposed hardware, stays closed on level floors | |
|---|---|---|
| Top surface use | Flat level surface sized to hold table lamps, small books, phone chargers and decorative items | |
| Floor cleaning access | 150 mm under-body clearance allows standard robot vacuum and broom access without moving the unit | |
| Stability design | Five-point leg support (four splayed outer legs + one central rear leg) reduces tipping risk when loaded on one edge | |
| Assembly type | Flat-pack RTA assembly with cam-lock and screw connections, no special power tools required | |
| Floor protection | Rubber foot pads prevent scuffs and scratches on hardwood, tile and vinyl flooring, minimize sliding on smooth surfaces | |
| Storage function | Single enclosed drawer stores small bedroom essentials including reading glasses, chargers, notebooks and skincare items | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
经核验的外箱 / 毛重 / 组装 / 装柜数据
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
推荐空间 / 目标用户 / 使用方式
| Residential bedroom use | Placed adjacent to twin, full or queen size beds for bedside storage of nighttime essentials | |
|---|---|---|
| Living room accent use | Used as narrow end table beside sofas or armchairs to hold drinks, remotes and small decor | |
| Small space / studio use | Suitable for micro-apartments and studio units with limited floor space due to narrow compact footprint | |
| Short-term rental furnishing | Appropriate for Airbnb, homestay and serviced apartment fit-outs for durable, on-trend bedside storage | |
| Dormitory room use | Fits beside student dorm beds to hold study supplies, phone chargers and personal items | |
| Commercial hotel guest room use | Suitable for select-service hotel guest rooms as a compact bedside table with concealed storage |
欧洲市场准入与化学品要求
| EN 12521:2015 | Strength, durability and safety requirements applicable to residential storage furniture | |
|---|---|---|
| EN 14749:2016 | Safety requirements for domestic and kitchen storage units and worktops | |
| EN 717-1:2004 | Formaldehyde emission test method for wood-based panels used in furniture | |
| EN 13722:2004 | Test methods for strength and durability of furniture drawers and slides |
适用于中国市场项目的标准
| GB/T 3324-2017 | General technical requirements applicable for domestic wooden bedroom furniture quality checks | |
|---|---|---|
| GB 18584-2001 | Formaldehyde emission limit requirement for interior decoration wood-based panel furniture | |
| GB/T 4893.4-2013 | Surface abrasion resistance test method applicable to laminate furniture finish testing | |
| GB/T 4893.9-2013 | Surface cigarette burn resistance test method applicable to horizontal top surfaces |
本产品须满足以下技术参数要求： 1. GB/T 3324-2017：General technical requirements applicable for domestic wooden bedroom furniture quality checks； 2. GB 18584-2001：Formaldehyde emission limit requirement for interior decoration wood-based panel furniture； 3. GB/T 4893.4-2013：Surface abrasion resistance test method applicable to laminate furniture finish testing； 4. GB/T 4893.9-2013：Surface cigarette burn resistance test method applicable to horizontal top surfaces； 最终交付参数、检测报告和验收标准以双方采购合同为准。
