商品供应商Luxury Low-Profile Modular Sectional Sofa with Left Chaise, Woven Frame, White Upholstery，Handwoven lattice synthetic weave over 1.5mm powder-coated aluminum subframe
可联系供应商获取生产周期与报价。
PRODUCT MODULE 01 / 06
基础物理尺寸
mm / 英寸自动双单位换算 · 工程采购基础规格
数据来源：工厂资料结构化字段，最终以实测值为准
| 产品外部尺寸（宽 × 深 × 高） | 3680 × 1800 × 860 mm | |
|---|---|---|
| Overall footprint | 3680 x 1800 x 860 mm | |
| Seat height from floor | 420 mm | |
| Standard seat depth (main seating) | 600 mm | |
| Chaise lounge extended depth | 1300 mm | |
| Backrest height above seat | 440 mm | |
| Armrest width at outer edge | 270 mm | |
| Seat cushion thickness | 370 mm | |
| Single main seating module width | 900 mm | |
| Decorative throw pillow dimension | 450 mm | |
| Floor clearance under base | 20 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
PRODUCT MODULE 02 / 06
重量、承重与性能参数
净重 / 最大承重 / 适用人数 / 耐久性能
数据来源：产品性能数据，采购前请核对具体测试口径
| Total product weight | 285 kg | |
|---|---|---|
| Per-seat static load capacity | 113 kg | |
| Upholstery abrasion resistance | 72500 Martindale cycles | |
| Seat cushion foam density | 30 kg/m³ | |
| Seat deck spring support rating | 50000 cycle durability | |
| Total seating capacity | 4 people | |
| Frame structural warranty | 5 years | |
| Fabric wear warranty | 1 year | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
PRODUCT MODULE 03 / 06
材质与结构参数
工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料
数据来源：以工厂材质清单与验货报告为准
| Exposed outer frame | Handwoven lattice synthetic weave over 1.5mm powder-coated aluminum subframe | |
|---|---|---|
| Seat core padding | 30kg/m³ PU foam + HR foam + memory foam layered stack | |
| Backrest padding | Feather and siliconized polyester fiber blend | |
| Upholstery fabric | Stain-resistant performance polyester-cotton blend | |
| Seat support system | 8-gauge sinuous steel springs with elastic webbing | |
| Base glides | Non-marking hard plastic floor glides | |
| Modular connection hardware | Zinc-plated steel locking connector brackets | |
| Throw pillow covers | Matching woven and solid performance fabric | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
PRODUCT MODULE 04 / 06
功能与调节参数
升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能
数据来源：功能配置参数，以供应商正式规格为准
| Modular reconfiguration | Steel bracket connected modules support left/right chaise orientation swap | |
|---|---|---|
| Cushion maintenance | Zippered removable seat and back cushion covers for spot cleaning | |
| Lounge support | Extended left chaise provides full leg rest for reclined relaxed seating | |
| Floor protection | Low-profile non-marking glides prevent scuffing on hard flooring surfaces | |
| Configuration expansion | Compatible with additional terminal, corner, or ottoman modules to extend seating length | |
| Stable interlock | Steel locking brackets prevent module separation during regular seating use | |
| Low-profile design | Minimal base height creates unobstructed sight lines across open-plan penthouse spaces | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
PRODUCT MODULE 05 / 06
包装与物流参数
经核验的外箱 / 毛重 / 组装 / 装柜数据
数据来源：外贸报价与装柜测算参考
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
PRODUCT MODULE 06 / 06
应用场景与使用方式
推荐空间 / 目标用户 / 使用方式
数据来源：依据产品结构与品类整理的推荐应用场景
| High-rise luxury residential living rooms | Low-profile design preserves panoramic window views in penthouse spaces | |
|---|---|---|
| Upscale hotel penthouse suites | Durable performance upholstery supports frequent guest use | |
| Open-plan lounge and entertaining areas | Four-seat capacity accommodates small group gatherings | |
| Contemporary minimalist interior schemes | Neutral white and warm brown palette complements modern decor | |
| Sky lounge and executive residential common areas | Premium construction supports high-end shared space use |
STANDARD S1
欧盟市场准入要求 * EN 标准
欧洲市场准入与化学品要求
| EN 1022:2018 | Applicable to domestic furniture seating for stability performance testing | |
|---|---|---|
| EN 12520:2015 | Applicable to residential seating for strength, durability and safety requirements |
STANDARD S3
适用于中国市场项目的标准 * GB 标准
适用于中国市场项目的标准
| GB/T 1952.1-2012 | Applicable to upholstered sofas for furniture strength and durability testing | |
|---|---|---|
| GB 18401-2010 | Applicable to textile upholstery for formaldehyde and harmful substance limits | |
| GB 28007-2011 | Applicable to upholstered furniture for children and general residential safety requirements |
招标文件标准化描述文本
本产品须满足以下技术参数要求： 1. GB/T 1952.1-2012：Applicable to upholstered sofas for furniture strength and durability testing； 2. GB 18401-2010：Applicable to textile upholstery for formaldehyde and harmful substance limits； 3. GB 28007-2011：Applicable to upholstered furniture for children and general residential safety requirements； 最终交付参数、检测报告和验收标准以双方采购合同为准。
