Luxury Low-Profile Modular Sectional Sofa with Left Chaise, Woven Frame, White Upholstery (model MS-WC-LCH-01) is listed under Fabric Office Sofa. Dimensions: 3680 × 1800 × 860 mm. Materials: Handwoven lattice synthetic weave over 1.5mm powder-coated aluminum subframe. Load capacity: 113 kg. Product Features: contemporary,luxury,style,modular,L-shaped,configuration,removable,cushion,upholstery. This page consolidates 6 groups of specifications and GB / EN standard references, with metric and imperial units. 1 supplier(s) are listed and you can request a quote online.
| Brand | JUESHANGDA | Model | MS-WC-LCH-01 |
| Overall dimensions (W × D × H) | 3680 × 1800 × 860 mm | Overall footprint | 3680 x 1800 x 860 mm |
| Seat height from floor | 420 mm | Standard seat depth (main seating) | 600 mm |
| Chaise lounge extended depth | 1300 mm | Backrest height above seat | 440 mm |
| Armrest width at outer edge | 270 mm | Seat cushion thickness | 370 mm |
| Single main seating module width | 900 mm | Decorative throw pillow dimension | 450 mm |
| Floor clearance under base | 20 mm | Back Cushion Thickness | 160 mm |
| Leg Height / Floor Clearance | 160 mm | Total product weight | 285 kg |
| Per-seat static load capacity | 113 kg | Upholstery abrasion resistance | 72500 Martindale cycles |
| Seat cushion foam density | 30 kg/m³ | Seat deck spring support rating | 50000 cycle durability |
| Total seating capacity | 4 people | Frame structural warranty | 5 years |
| Fabric wear warranty | 1 year | Seat Foam Density / Rebound | 40 kg/m³ / 60% |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm | Exposed outer frame | Handwoven lattice synthetic weave over 1.5mm powder-coated aluminum subframe |
| Seat core padding | 30kg/m³ PU foam + HR foam + memory foam layered stack | Backrest padding | Feather and siliconized polyester fiber blend |
| Upholstery fabric | Stain-resistant performance polyester-cotton blend | Seat support system | 8-gauge sinuous steel springs with elastic webbing |
| Base glides | Non-marking hard plastic floor glides | Modular connection hardware | Zinc-plated steel locking connector brackets |
| Throw pillow covers | Matching woven and solid performance fabric | Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options | Modular reconfiguration | Steel bracket connected modules support left/right chaise orientation swap |
| Cushion maintenance | Zippered removable seat and back cushion covers for spot cleaning | Lounge support | Extended left chaise provides full leg rest for reclined relaxed seating |
| Floor protection | Low-profile non-marking glides prevent scuffing on hard flooring surfaces | Configuration expansion | Compatible with additional terminal, corner, or ottoman modules to extend seating length |
| Stable interlock | Steel locking brackets prevent module separation during regular seating use | Low-profile design | Minimal base height creates unobstructed sight lines across open-plan penthouse spaces |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods | Reference Package Count | 1 set / 2 cartons |
| Reference Assembly Time | 40 minutes per set | Reference Module Carton Dimensions | 2200× 1050× 850 mm |
| Reference Packaging Volume | 1.8 m³/item | Reference Packaged Gross Weight | 110 kg/item |
| High-rise luxury residential living rooms | Low-profile design preserves panoramic window views in penthouse spaces | Upscale hotel penthouse suites | Durable performance upholstery supports frequent guest use |
| Open-plan lounge and entertaining areas | Four-seat capacity accommodates small group gatherings | Contemporary minimalist interior schemes | Neutral white and warm brown palette complements modern decor |
| Sky lounge and executive residential common areas | Premium construction supports high-end shared space use | — | — |
| Time | Field | Original Value | Corrected Value | Note / Status |
|---|---|---|---|---|
No correction records yet. Found an error? Click the flag at the end of a row to report it. | ||||
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 3680 × 1800 × 860 mm | |
|---|---|---|
| Overall footprint | 3680 x 1800 x 860 mm | |
| Seat height from floor | 420 mm | |
| Standard seat depth (main seating) | 600 mm | |
| Chaise lounge extended depth | 1300 mm | |
| Backrest height above seat | 440 mm | |
| Armrest width at outer edge | 270 mm | |
| Seat cushion thickness | 370 mm | |
| Single main seating module width | 900 mm | |
| Decorative throw pillow dimension | 450 mm | |
| Floor clearance under base | 20 mm | |
| Back Cushion Thickness | 160 mm | |
| Leg Height / Floor Clearance | 160 mm |
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product weight | 285 kg | |
|---|---|---|
| Per-seat static load capacity | 113 kg | |
| Upholstery abrasion resistance | 72500 Martindale cycles | |
| Seat cushion foam density | 30 kg/m³ | |
| Seat deck spring support rating | 50000 cycle durability | |
| Total seating capacity | 4 people | |
| Frame structural warranty | 5 years | |
| Fabric wear warranty | 1 year | |
| Seat Foam Density / Rebound | 40 kg/m³ / 60% | |
| Upholstery Abrasion Reference | Fabric 60000 cycles; leather-class cover 1.4 mm |
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Exposed outer frame | Handwoven lattice synthetic weave over 1.5mm powder-coated aluminum subframe | |
|---|---|---|
| Seat core padding | 30kg/m³ PU foam + HR foam + memory foam layered stack | |
| Backrest padding | Feather and siliconized polyester fiber blend | |
| Upholstery fabric | Stain-resistant performance polyester-cotton blend | |
| Seat support system | 8-gauge sinuous steel springs with elastic webbing | |
| Base glides | Non-marking hard plastic floor glides | |
| Modular connection hardware | Zinc-plated steel locking connector brackets | |
| Throw pillow covers | Matching woven and solid performance fabric | |
| Timber Frame Section / Moisture | Primary section ≥30 × 50 mm; recommended moisture 12% | |
| Spring / Webbing Specification | Sinuous spring wire 4 mm; elastic webbing 70 mm wide | |
| Leg Connector Specification | Reference M8-M10 with at least 1 mechanical fixing per leg | |
| Reference Upholstery Color Count | Recommended 8fabric/leather color options |
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Modular reconfiguration | Steel bracket connected modules support left/right chaise orientation swap | |
|---|---|---|
| Cushion maintenance | Zippered removable seat and back cushion covers for spot cleaning | |
| Lounge support | Extended left chaise provides full leg rest for reclined relaxed seating | |
| Floor protection | Low-profile non-marking glides prevent scuffing on hard flooring surfaces | |
| Configuration expansion | Compatible with additional terminal, corner, or ottoman modules to extend seating length | |
| Stable interlock | Steel locking brackets prevent module separation during regular seating use | |
| Low-profile design | Minimal base height creates unobstructed sight lines across open-plan penthouse spaces | |
| Cushion Service Configuration | Recommended 2removable/replaceable cushion methods |
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Module Carton Dimensions | 2200× 1050× 850 mm | |
| Reference Packaging Volume | 1.8 m³/item | |
| Reference Packaged Gross Weight | 110 kg/item |
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| High-rise luxury residential living rooms | Low-profile design preserves panoramic window views in penthouse spaces | |
|---|---|---|
| Upscale hotel penthouse suites | Durable performance upholstery supports frequent guest use | |
| Open-plan lounge and entertaining areas | Four-seat capacity accommodates small group gatherings | |
| Contemporary minimalist interior schemes | Neutral white and warm brown palette complements modern decor | |
| Sky lounge and executive residential common areas | Premium construction supports high-end shared space use |
EU Market Access Requirements* EN Standards
| EN 1022:2018 | Applicable to domestic furniture seating for stability performance testing | |
|---|---|---|
| EN 12520:2015 | Applicable to residential seating for strength, durability and safety requirements |
Standards applicable to China-market projects
| GB/T 1952.1-2012 | Applicable to upholstered sofas for furniture strength and durability testing | |
|---|---|---|
| GB 18401-2010 | Applicable to textile upholstery for formaldehyde and harmful substance limits | |
| GB 28007-2011 | Applicable to upholstered furniture for children and general residential safety requirements |
This product must meet the following technical requirements: 1. GB/T 1952.1-2012: Applicable to upholstered sofas for furniture strength and durability testing; 2. GB 18401-2010: Applicable to textile upholstery for formaldehyde and harmful substance limits; 3. GB 28007-2011: Applicable to upholstered furniture for children and general residential safety requirements; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
