5000mm Serpentine Dual-Station Curved Commercial Reception Desk Specifications

RCV-S5000-DS

代码:LK2MWVV1
获取供应商报价
2026-09-17 12:00人气: 2
参数纠错历史记录(所有访客可见)
纠错时间修改字段原参数修改后参数说明 / 状态
暂无参数纠错记录,发现错误可点击行末旗标提交

RCV-S5000-DS

1家生产中供应商 >>
PRODUCT MODULE 01 / 06

基础物理尺寸

mm / 英寸自动双单位换算 · 工程采购基础规格

Overall footprint5000 x 800 x 1100 mm
Front transaction counter height1100 mm
Inner seated work surface height750 mm
Maximum counter depth800 mm
Work surface depth per station700 mm
Side outer curved arc length2094 mm
Inner concave work arc length per station866 mm
End cap arc dimension per side1681 mm
Central convex front arc length1864 mm
Seated knee clearance height under work surface650 mm
Countertop overhang50 mm
Solid surface countertop thickness25 mm
Edge banding thickness2 mm
Finished Top Thickness50 mm
Effective Knee Clearance680 mm high and 900 mm wide per main seat
Leg / Support Section80 mm main section with 2 mm metal wall
PRODUCT MODULE 02 / 06

重量、承重与性能参数

净重 / 最大承重 / 适用人数 / 耐久性能

Countertop static load capacity150 kg
Total assembled unit weight400 kg
Staff seating capacity2
Countertop flexural strength60 MPa
Countertop compressive strength45 MPa
Substrate formaldehyde emission0.5 mg/L
Drawer slide load rating per drawer25 kg
Surface abrasion resistance400 cycles
Top Static Load Reference150 kg uniformly distributed
Drawer Slide Load / Life45 kg/pair; 50000 cycles
PRODUCT MODULE 03 / 06

材质与结构参数

工程采购验收核心字段 · 面板基材 / 五金 / 框架 / 面料

Transaction countertop25mm seamless acrylic artificial stone, high-gloss finish
Inner work surface substrateE0 grade moisture-resistant solid particle board, melamine laminate backing
Edge banding2mm thick PVC edge trim, impact and stain resistant
Support frame1.5mm thick powder-coated square steel tubing, corrosion resistant
Cabinet panel finishFlame-retardant melamine laminate, scratch resistant finish
Undercounter drawer boxes18mm thick particle board, full-extension ball-bearing slides
Optional front accent trimBrushed stainless steel kick plate, 1mm thick, polished finish
Cable management grommetsABS plastic, 80mm diameter, matching countertop color
Primary Panel Thickness25 mm; load-bearing top may use 40 mm composite build-up
Edge Band Thickness2 mm
Metal Frame Wall Thickness2 mm cold-rolled steel
Primary Connector SpecificationReference M6-M8 with at least 2 fixing points per main support
PRODUCT MODULE 04 / 06

功能与调节参数

升降 / 旋转 / 倾仰 / 锁定 / 移动 / 储物功能

Dual-height stepped counter design1100mm front transaction surface and 750mm inner work surface
Dual independent workstationsTwo separate concave work zones with dedicated undercounter storage
Undercounter storage systemTwo suspended drawer units and open equipment bays under each work surface
Integrated cable management80mm diameter grommets and under-desk cable tray per workstation
Seamless curved counter spliceOn-site bonded solid surface joints with no visible seams
Leveling adjustmentM8 adjustable feet at support points, 15mm adjustment range
Optional LED accent lightingRecessed LED strip along front counter kick plate, 3000K warm white
Floor anchoring provisionPre-drilled anchor points at steel support legs for secure fixing
Cable Management CapacityReference capacity 10power/data cables; tray load 10 kg
Reference Reassembly CountMain joints should support 5controlled assembly cycles
PRODUCT MODULE 05 / 06

包装与物流参数

经核验的外箱 / 毛重 / 组装 / 装柜数据

Reference Package Count1 set / 2 cartons
Reference Assembly Time40 minutes per set
Reference Package DimensionsMain top 2500× 1050× 350 mm; return/pedestal packed separately
Reference Packaged Gross Weight180 kg/set in 4 cartons
Reference Packaging Volume1 m³/set
PRODUCT MODULE 06 / 06

应用场景与使用方式

推荐空间 / 目标用户 / 使用方式

Commercial office main lobbySuitable for corporate entrance reception, visitor check-in and guest greeting
Hotel front deskDurable seamless surface and dual-station layout for continuous guest service
Public service center hallLong curved profile accommodates multiple visitor service points efficiently
Exhibition hall information counterAttractive curved silhouette directs visitor traffic and provides consultation space
High-end medical clinic receptionNon-porous easy-to-clean surface meets public space hygiene requirements
Dual-receptionist configurationTwo separate work zones reduce cross-interference during peak service periods
STANDARD S1

欧盟市场准入要求 * EN 标准

欧洲市场准入与化学品要求

EN 15372:2008+A1:2016Office furniture durability, strength and safety requirements for non-domestic storage units
EN 13722:2004Test methods for surface resistance to cold liquids for furniture worktops
EN 1022:2018Seating and work surface stability requirements for commercial workstations
STANDARD S2

北美市场采购验货参考 * ANSI/BIFMA 标准

美国及加拿大家具标准

ANSI/BIFMA X5.5-2021Desk products safety and performance standard for office work surfaces
ANSI/BIFMA X5.9-2019Storage units safety and durability standard for undercounter cabinetry
ANSI/BIFMA e3-2019eFurniture sustainability standard for material emissions and environmental impact
STANDARD S3

适用于中国市场项目的标准 * GB 标准

适用于中国市场项目的标准

GB/T 3324-2017General technical requirements for wooden office furniture, applicable to cabinet substrate and finish
GB 18580-2017Formaldehyde emission limits for wood-based panels, required for indoor commercial furniture
GB/T 35607-2017Green product evaluation standard for furniture, applicable for low-emission material selection
招标文件标准化描述文本
本产品须满足以下技术参数要求:
1. GB/T 3324-2017:General technical requirements for wooden office furniture, applicable to cabinet substrate and finish;
2. GB 18580-2017:Formaldehyde emission limits for wood-based panels, required for indoor commercial furniture;
3. GB/T 35607-2017:Green product evaluation standard for furniture, applicable for low-emission material selection;
最终交付参数、检测报告和验收标准以双方采购合同为准。
GENERATED EXPORTS

一键导出完整商品资料

以下文件均根据当前已发布商品参数实时生成。

完整参数报告 PDF

直接下载英文参数报告,可选择公制或英制单位。

PDF · RCV-S5000-DS

完整参数 Excel

导出全部商品信息与参数模块,文件内容统一使用英文。

XLSX · RCV-S5000-DS

外贸 Listing 模板

包含英文标题、规格、材质、标准和采购字段,可用于国际平台刊登。

XLSX · LISTING

海关申报数据

生成申报品名、材质、用途、尺寸及海关申报要素。

CUSTOMS · RCV-S5000-DS打开导出工具

页面快速操作

发布采购询价

产品描述

The 5000mm Serpentine Dual-Station Curved Commercial Reception Desk, model RCV-S5000-DS, is an unbranded front-of-house furniture piece designed for high-traffic public and commercial settings. Its defining visual feature is a smooth, continuous serpentine curved form with a stepped dual-height profile: the 1100mm tall front transaction counter creates a polished guest-facing facade, while the concave inner work surface sits at 750mm to support comfortable seated work for staff. The seamless, high-gloss countertop forms a unified, elegant silhouette, with optional brushed stainless steel kick plate or recessed 3000K warm white LED strip lighting available to accent the front facade. Each end of the desk incorporates a curved end cap, balancing the extended length with soft, flowing lines that guide visitor movement and avoid sharp, obtrusive corners. Constructed for heavy commercial use, the desk features a 25mm seamless acrylic artificial stone transaction countertop, with load-bearing sections built up to a 40mm composite thickness for enhanced stability. The inner work surface uses E0 grade moisture-resistant solid particleboard with a flame-retardant, scratch-resistant melamine laminate backing, and all edges are finished with 2mm thick impact- and stain-resistant PVC trim. A 1.5mm thick corrosion-resistant powder-coated square steel support frame forms the structural core, with undercounter drawer boxes made from 18mm thick particleboard fitted with full-extension ball-bearing slides. The countertop delivers 60 MPa flexural strength, 45 MPa compressive strength, and a 150 kg static load capacity, with each drawer rated to hold 25 kg. Substrate formaldehyde emission measures 0.5 mg/L, and the non-porous solid surface supports simple, thorough cleaning. Functional design elements are tailored to efficient front-of-house operations: two independent concave work zones, each with 700mm work surface depth, accommodate two staff members with minimal cross-interference during peak service periods. Each station includes suspended drawer units and open equipment bays for storage, plus 80mm diameter color-matched ABS cable grommets and an under-desk cable tray to organize power and data cords. M8 adjustable feet offer 15mm of height adjustment to level the unit on uneven floors, and on-site bonded solid surface joints create a completely seamless countertop free of visible gaps. This desk is suited for a range of public-facing spaces: corporate office main lobbies for visitor check-in and greeting, hotel front desks for continuous guest service, public service center halls for multi-point visitor support, exhibition hall information counters for traffic direction and consultation, and high-end medical clinic receptions where easy-to-clean surfaces support hygiene needs. For procurement, note the unit has a total assembled weight of 400 kg, ships with a reference packaging volume of 1 cubic meter per set, and requires 40 minutes of on-site assembly per unit. Buyers may select the optional stainless steel kick plate or LED accent lighting at the time of order to align with interior design schemes.
