Automatic mm / inch conversion · Core engineering specifications
| Overall footprint | 2304 x 2060 x 1100 mm | |
|---|---|---|
| Mattress interface | 1930 x 2030 mm | |
| Headboard overall size | 2060 x 240 x 1100 mm | |
| Upper headboard cushion size | 980 x 220 x 120 mm per cushion, 2 pieces | |
| Lower headboard panel size | 980 x 300 x 90 mm per panel, 2 pieces | |
| Side rail size | 2130 x 180 x 300 mm each, 2 pieces | |
| Foot rail size | 2060 x 180 x 300 mm | |
| Platform support height | 320 mm from floor to top of slat deck | |
| Sleeping surface height | 520 mm including a 200 mm mattress | |
| Under-bed clearance | 120 mm high x 1700 mm wide under the central deck | |
| Leg and base footprint | 25 x 25 mm square metal tube with 120 mm legs | |
| Slat support zone | 1930 x 2000 mm | |
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Static load capacity | 363 kg | |
|---|---|---|
| Recommended mattress weight | 55 kg | |
| Occupant capacity | 2 adults | |
| Bed frame net weight | 58 kg | |
| Slat count | 14 slats | |
| Individual slat load | 35 kg static per slat | |
| Center support legs | 3 legs | |
| Fabric seam spacing | 80 mm maximum seam pitch | |
| Mattress thickness suitability | 200 mm | |
| Warranty duration | 24 months |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard substrate | Engineered-wood or plywood panel, 18 mm nominal, fully wrapped and padded | |
|---|---|---|
| Headboard cushion padding | 38 kg/m3 polyurethane foam, 120 mm thick on upper cushions | |
| Rail padding | High-resilience polyurethane foam, 30 mm thick, bonded to the rail frame | |
| Upholstery fabric | Mustard polyester woven fabric, 320 g/m2 nominal | |
| Mattress visible in photo | Quilted light-beige knitted fabric over foam or hybrid mattress core | |
| Slat system | Bent laminated beech or birch wood slats, 55 x 12 mm nominal | |
| Center beam | Rectangular engineered-wood rail, 60 x 40 mm nominal, with three support feet | |
| Legs and perimeter base | Dark bronze powder-coated square steel tube, 25 x 25 x 1.2 mm nominal | |
| Corner blocks | 18 mm plywood or hardwood corner blocks with M8 connector hardware | |
| Fasteners | M8 x 80 mm barrel bolts and cam connectors, 16 sets minimum | |
| Under-bed shadow panel | Black non-woven fabric or dark recessed base panel | |
| Edge stitching | Polyester sewing thread with 3 stitches per 10 mm |
Adjustment / rotation / tilt / mobility / storage features
| Platform support | Wood slat deck supports the mattress directly and removes the need for a box spring | |
|---|---|---|
| Center load distribution | One longitudinal beam and three floor legs divide the mattress area into reinforced support zones | |
| Headboard cushion layout | Two upper loose padded cushions and two fixed lower padded panels form a four-section backrest | |
| Rail retention | Bolt-on side and foot rails connect to the headboard and corner posts with knock-down hardware | |
| Floor contact | Four corner metal legs plus three center support legs transfer loads directly to the floor | |
| Under-bed access | 120 mm open clearance permits robot vacuum access and limited under-bed cleaning | |
| Mattress retention | Upholstered 300 mm rails surround the mattress and limit lateral movement | |
| Assembly method | Two-person bolt-together assembly using included Allen key and hardware kit | |
| Storage configuration | No drawers, gas-lift storage compartment or hydraulic mechanism is present | |
| Room placement | Headboard designed for wall placement with three open mattress-access sides | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Primary bedroom | Suits a king or super-king residential bedroom where a low upholstered frame and soft backrest are required | |
|---|---|---|
| Boutique hotel guest room | Fits contemporary hotel rooms seeking a warm mustard accent without built-in case goods | |
| Apartment furnishing project | Suitable for turn-key residential packages using flat-pack transport and two-person on-site assembly | |
| Showroom or model home | Appropriate for modern bedroom displays where the four-panel padded headboard is a visual focal point | |
| Bedroom with robot vacuum | 120 mm under-bed clearance supports routine floor-cleaning access | |
| Low-profile mattress styling | Pairs with a 200 mm mattress for a clean tailored sleeping surface height of 520 mm | |
| Neutral-wall interiors | Mustard upholstery provides a single warm color element against gray, white or beige walls |
EU Market Access Requirements* EN Standards
| Domestic bedding dimensions | EN 1334:1996 | |
|---|---|---|
| Furniture strength and durability | EN 1725:1998 | |
| Formaldehyde panels | EN 312:2010 |
Standards applicable to China-market projects
| Bed dimensional reference | GB/T 3328 | |
|---|---|---|
| Wood-based panels | GB 18580 | |
| Upholstered furniture safety | GB 28007 | |
| Furniture mechanical testing | GB/T 10357.6 |
This product must meet the following technical requirements: 1. Bed dimensional reference: GB/T 3328; 2. Wood-based panels: GB 18580; 3. Upholstered furniture safety: GB 28007; 4. Furniture mechanical testing: GB/T 10357.6; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
