Automatic mm / inch conversion · Core engineering specifications
| Overall bed dimensions | 1980 x 2220 x 1050 mm | |
|---|---|---|
| Side Rail Thickness | 40 mm | |
| Slat Spacing | 80 mm | |
| Center Support Leg Count | Recommended 6legs |
Net weight / load capacity / users / durability
| Net weight | 72 kg | |
|---|---|---|
| Recommended mattress weight | 55 kg | |
| Static bed-frame load | 350 kg | |
| Slat system distributed load | 180 kg | |
| Occupant capacity | 2 adults | |
| Recommended mattress thickness | 260 mm | |
| Hardware cycle target | 10,000 assembly-side cycles | |
| Color options represented | 1 charcoal finish visible | |
| Bed Static Load Reference | 400 kg | |
| Per-slat Load Reference | 60 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Headboard upholstery | Charcoal woven textile-look fabric over soft padding | |
|---|---|---|
| Side and foot rails | Upholstered engineered-wood frame with matching charcoal outer layer | |
| Head cushion construction | Two independently shaped padded cushions with recessed diagonal seam detail | |
| Internal support board | Plywood or engineered-wood bed frame at 25 mm thickness | |
| Slat system | Flexible timber or composite slats on a central support rail at 28 mm slat width | |
| Support legs | Four slim silver-finish metal legs at 32 mm upper diameter | |
| Rail padding | 15 mm polyurethane padding under upholstery on side and foot rails | |
| Headboard inner filling | 35 kg/m3 polyurethane foam with fiber topping at 80 mm thickness | |
| Joint hardware | Carbon-steel bolts, barrel nuts, and corner brackets with black oxide or zinc plating | |
| Mattress contact layer | Breathable slatted support surface without solid board | |
| Surface abrasion target | 30,000 Martindale cycles for residential upholstery | |
| Seam construction | Reinforced sewn or tucked cushion edges with 8 stitches per 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Sleeping configuration | Two-adult queen-size platform designed for an 1800 x 2000 mm mattress | |
|---|---|---|
| Head support | Two padded back cushions provide upright reading support across the full 1980 mm width | |
| Mattress retention | Upholstered side and foot rails contain the mattress on the internal platform | |
| Under-bed access | 120 mm clearance permits robotic vacuum access and limited under-bed air circulation | |
| Assembly method | Knock-down bolted assembly connects headboard, side rails, foot rail, slats, and legs | |
| Support layout | Four corner legs plus a central longitudinal support beam carry the slat system | |
| Floor protection | Small floor-contact feet on slim metal legs reduce concentrated loading | |
| Placement requirement | Headboard is intended for wall placement with 50 mm rear clearance | |
| Storage provision | No drawers or lift-up storage mechanism are visible | |
| Maintenance access | Removable mattress allows access to slats and central support without disassembling outer rails | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Headboard carton dimensions | 2050 x 1120 x 220 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2300× 900× 450 mm/carton in 4 cartons | |
| Reference Packaged Gross Weight | 130 kg/set | |
| Reference Packaging Volume | 0.9 m³/set |
Recommended spaces / users / usage modes
| Main bedroom | Suits a queen-size bedroom for two adults seeking a soft modern upholstered headboard | |
|---|---|---|
| Guest suite | Fits serviced apartments or guest rooms requiring hotel-like comfort and restrained charcoal styling | |
| Contemporary residential interior | Pairs with concrete, white, gray, wood, or monochrome palettes seen in the room image | |
| Reading-in-bed setup | Padded two-cushion headboard supports upright reading or tablet use with bed pillows | |
| Compact luxury bedroom | Low 420 mm foot rail reduces visual mass while preserving a substantial 1050 mm headboard | |
| Bedding coordination | Works with white, light gray, charcoal, or textured textiles and a 240 to 260 mm mattress | |
| Flooring compatibility | Suitable for low-pile carpet, rug, wood-look, or hard floors with protective feet |
EU Market Access Requirements* EN Standards
| Furniture safety suggestion | EN 1725 for domestic bed safety, strength, and durability |
|---|
Standards applicable to China-market projects
| Formaldehyde emission suggestion | GB/T 39600 E1 limit for engineered-wood components | |
|---|---|---|
| Upholstered furniture safety suggestion | GB/T 33241 for domestic furniture with upholstered soft surfaces | |
| Furniture mechanical test suggestion | GB/T 10357.6 for bed strength and stability test methods |
This product must meet the following technical requirements: 1. Formaldehyde emission suggestion: GB/T 39600 E1 limit for engineered-wood components; 2. Upholstered furniture safety suggestion: GB/T 33241 for domestic furniture with upholstered soft surfaces; 3. Furniture mechanical test suggestion: GB/T 10357.6 for bed strength and stability test methods; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
