Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1000 x 1000 x 750 mm | |
|---|---|---|
| Tabletop diameter | 1000 mm | |
| Tabletop thickness | 20 mm | |
| Under-table knee clearance height | 680 mm | |
| Leg outer spread diameter at floor | 920 mm | |
| Tubular leg diameter | 25 mm | |
| Horizontal cross-brace height from floor | 320 mm | |
| Rounded tabletop edge radius | 10 mm | |
| Floor contact foot diameter | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Net weight | 32 kg | |
|---|---|---|
| Distributed tabletop static load | 100 kg | |
| Recommended seating capacity | 4 people | |
| Surface scratch resistance rating | 6H | |
| Surface water absorption rate | 0.05% | |
| Frame static load per leg | 35 kg | |
| Recommended service life | 8 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | Engineered artificial marble composite | |
|---|---|---|
| Tabletop finish | Smooth low-sheen sealed surface | |
| Leg frame tubing | Powder-coated carbon steel | |
| Joint connectors | Zinc-plated steel M6 bolts | |
| Floor glides | Injection-molded non-scratch polypropylene | |
| Frame weld joints | TIG-welded steel intersections | |
| Top surface coating thickness | 0.2 mm | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop configuration | Fixed non-extendable round surface | |
|---|---|---|
| Assembly requirement | Flat-pack knock-down assembly | |
| Floor protection | Non-marking PP glides at each leg end | |
| Seating access | Four open quadrants between splayed legs | |
| Surface maintenance | Wipe-clean non-porous top | |
| Frame stability | Interlocking bent-tube cross brace | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining nook | Fits small apartments and kitchen dining areas for 4-person meals | |
|---|---|---|
| Cafe and bistro seating | Suitable for casual commercial dining areas with lightweight modern aesthetic | |
| Balcony casual dining | Weather-resistant sealed top and powder-coated frame for covered outdoor use | |
| Open-plan studio spaces | Minimalist silhouette does not visually clutter compact open living areas | |
| Small office break room | Provides compact dining surface for employee meal breaks and casual meetings |
EU Market Access Requirements* EN Standards
| Domestic furniture strength | EN 12521:2015 | |
|---|---|---|
| Surface wear resistance | EN 15186:2012 |
Standards applicable to China-market projects
| Table structural stability | GB/T 3324 | |
|---|---|---|
| Surface coating adhesion | GB/T 4893.4 | |
| Steel tube frame anti-corrosion | GB/T 1993 |
This product must meet the following technical requirements: 1. Table structural stability: GB/T 3324; 2. Surface coating adhesion: GB/T 4893.4; 3. Steel tube frame anti-corrosion: GB/T 1993; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
