Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 600 x 600 x 880 mm | |
|---|---|---|
| Seat height (floor to seat top) | 470 mm | |
| Seat width (between integrated armrests) | 520 mm | |
| Seat depth (front to rear) | 485 mm | |
| Backrest height (seat top to back crest) | 410 mm | |
| Integrated armrest height (seat top to arm surface) | 200 mm | |
| Leg taper angle (vertical offset) | 8 degrees | |
| Leg cross-section diameter at floor | 25 mm | |
| Seat cushion thickness | 115 mm | |
| Upholstered shell wall thickness | 25 mm | |
| Footprint width at leg base | 560 mm | |
| Footprint depth at leg base | 550 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 14 kg | |
|---|---|---|
| Recommended static user weight capacity | 160 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam rebound rate | 45% | |
| Backrest foam thickness | 40 mm | |
| Faux leather upholstery abrasion resistance (Martindale) | 50000 cycles | |
| Static leg load rating per leg | 60 kg | |
| Standard warranty period | 365 days | |
| Available color count | 6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and back upholstery | 1.2mm thick cognac faux leather with matte finish | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam wrapped in polyester dacron | |
| Backrest and integrated armrest shell | 15mm thick plywood internal frame with foam padding | |
| Legs | 1.5mm thick matte black powder-coated steel tube, tapered design | |
| Seat support base | 1.2mm thick black powder-coated steel perimeter frame | |
| Seat support webbing | 50mm wide elastic webbing spaced 80mm apart under seat cushion | |
| Foot pads | 8mm diameter non-slip polyethylene floor glides at each leg base | |
| Upholstery stitching | 10mm seam pitch along curved shell edges | |
| Surface finish on metal components | Matte black powder coating, 60 micron thickness | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating support | Fixed upright position with 3-degree backward seat tilt for dining posture | |
|---|---|---|
| Integrated armrest support | Continuous curved armrests integrated with backrest shell for forearm support | |
| Floor protection | Non-marking glides on all leg bases to prevent hard floor scratches | |
| Cleaning and maintenance | Wipe-clean faux leather surface resistant to common food and liquid spills | |
| Assembly requirement | Knock-down assembly with legs attached to seat frame via included hardware | |
| Stacking capability | Non-stacking fixed frame design for permanent placement | |
| Weight distribution | Four-point leg support with outward angle to reduce tipping risk during use | |
| Arm clearance | 180mm vertical clearance under armrests to allow sliding under standard dining tables | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Carton dimensions (per 2 chairs) | 890 x 640 x 480 mm | |
|---|---|---|
| Gross weight per carton (2 chairs) | 32 kg | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining room use | Pairs with standard 750mm high dining tables for 6person dining sets | |
|---|---|---|
| Cafe and light restaurant use | Durable faux leather upholstery and stable frame suit high-traffic casual dining spaces | |
| Home office guest seating | Compact footprint fits beside desks for short-term visitor seating | |
| Apartment and small space dining | 600mm compact width fits small dining nooks and open-plan kitchen areas | |
| Hotel banquet and breakout area use | Contemporary design complements modern hospitality interiors | |
| Vanity and dressing table seating | Back and arm support works for seated grooming and dressing activities | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Furniture strength, durability and safety for domestic seating | |
|---|---|---|
| EN 1022:2018 | Furniture seating determination of stability | |
| EN 16139:2013 | Furniture strength, durability and safety for non-domestic seating |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal frame safety | |
|---|---|---|
| GB/T 16799-2008 | FurnitureUseartificial leather, applicable to faux leather upholstery performance | |
| GB 28007-2011 | General technical requirements for children's furniture, applicable if used in family settings | |
| GB/T 10357.3-2013 | Furniture mechanical performance test for chairs and stools |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal frame safety; 2. GB/T 16799-2008: FurnitureUseartificial leather, applicable to faux leather upholstery performance; 3. GB 28007-2011: General technical requirements for children's furniture, applicable if used in family settings; 4. GB/T 10357.3-2013: Furniture mechanical performance test for chairs and stools; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
