Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 520 x 630 x 864 mm | |
|---|---|---|
| Seat height | 450 mm | |
| Seat depth | 450 mm | |
| Seat width | 480 mm | |
| Backrest height | 430 mm | |
| Backrest width at top | 520 mm | |
| Leg taper diameter at floor | 20 mm | |
| Seat cushion thickness | 160 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 7.1 kg | |
|---|---|---|
| Maximum static user load | 125 kg | |
| Upholstery abrasion resistance | 50000 rub cycles | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 45% | |
| Seam stitch pitch | 8 stitches per inch | |
| Recommended daily usage duration | 8 hours per day | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Outer upholstery | 1.2mm thick matte faux leather | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam | |
| Backrest padding | 30mm thick medium-density polyurethane foam | |
| Internal support frame | 18mm thick multilayer plywood | |
| Leg internal support | Powder-coated carbon steel tube | |
| Bottom foot pads | Non-slip nylon glides | |
| Stitching detail | Matching color bonded polyester thread | |
| Upholstery surface finish | Matte scratch-resistant coating | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating orientation | Fixed upright position with 100° backrest angle | |
|---|---|---|
| Floor leveling | Fixed non-adjustable nylon glides at each leg base | |
| Space efficiency | Armless design allows tucking fully under standard 750mm height dining tables | |
| Seating clearance | 480mm clear seat width accommodates most adult users without arm restriction | |
| Maintenance feature | Wipe-clean non-porous upholstery surface | |
| Structural stability | Four-leg tapered layout provides 520mm wide support base | |
| Stacking compatibility | Non-stackable fixed construction | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Carton outer dimensions | 800 x 650 x 650 mm | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining room | Suitable for use with standard height dining tables for 6seat layouts | |
|---|---|---|
| Cafe and bistro seating | Durable wipe-clean surface suits high-turnover light commercial food service environments | |
| Hotel guest room and lounge | Compact armless profile works for in-room dining and secondary seating areas | |
| Office breakout area | Comfortable upright posture supports short meetings and casual work sessions | |
| Showroom and event staging | Available in multiple matte color options for coordinated interior display setups | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety requirements for domestic dining seating | |
|---|---|---|
| EN 1022:2018 | Stability test standard for non-domestic and residential seating |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for internal frame testing | |
|---|---|---|
| GB/T 16799-2008 | Specification for polyurethane synthetic leather used for furniture upholstery | |
| GB 28007-2011 | Limit of harmful substances in upholstered furniture for children and adult seating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for internal frame testing; 2. GB/T 16799-2008: Specification for polyurethane synthetic leather used for furniture upholstery; 3. GB 28007-2011: Limit of harmful substances in upholstered furniture for children and adult seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
