Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 480 x 520 x 1000 mm | |
|---|---|---|
| Seat height | 660 mm | |
| Seat surface dimensions | 480 x 390 mm | |
| Seat cushion thickness | 70 mm | |
| Backrest height above seat | 280 mm | |
| Footrest height above floor | 220 mm | |
| Leg splay base width | 500 mm | |
| Leg tube diameter | 19 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per unit | 13 kg | |
|---|---|---|
| Static load capacity | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| Foam rebound rate | 40% | |
| Upholstery abrasion resistance | 50000 double rubs | |
| Frame static load rating per leg | 40 kg | |
| Recommended user weight | 136 kg | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat upholstery | 0.8 mm thick tan faux leather, stain-resistant surface | |
|---|---|---|
| Seat padding | High-density polyurethane foam, contoured for comfort | |
| Backrest padding | Thin bonded foam layer over rigid shell, matching tan upholstery | |
| Outer seat/back shell | Matte black rigid polypropylene, structural support layer | |
| Frame and legs | 1.2 mm thick powder-coated black steel, tapered splayed design | |
| Footrest | Welded black steel crossbar, integrated with leg frame | |
| Foot pads | Non-slip rubber glides, floor protection at each leg base | |
| Seam construction | 8 mm stitch pitch, reinforced edge stitching on upholstery | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Height adjustment | Fixed 660 mm seat height, no swivel or lift mechanism | |
|---|---|---|
| Foot support | Dual horizontal welded steel footrests for both seating directions | |
| Back support | Low upright backrest for lumbar support during counter-height perching | |
| Floor protection | Rubber glides prevent hard floor scratches and reduce movement noise | |
| Seating access | Armless design allows side entry for tight kitchen island or bar layouts | |
| Frame stability | Splayed four-leg geometry provides anti-tip stability for elevated seating | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential kitchen islands | Suits 900 mm high kitchen counters for casual dining and meal prep seating | |
|---|---|---|
| Break room bar areas | Works for office break room elevated counter seating for short rest periods | |
| Cafe and bistro seating | Appropriate for modern industrial-style cafe bar counter customer seating | |
| Home bar spaces | Fits 1050 mm home bar surfaces for relaxed entertaining seating | |
| Compact balcony bar setups | Armless narrow footprint fits small space elevated balcony bar configurations | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Domestic seating strength and durability | EN 12520:2015 | |
|---|---|---|
| Furniture seating flammability | EN 1021:2014 |
US and Canada office-furniture standards
| Small office/home office seating | ANSI/BIFMA X2015 | |
|---|---|---|
| Seating stability testing | ANSI/BIFMA X2017Clause 6 |
Standards applicable to China-market projects
| General furniture mechanical safety | GB/T 3324 | |
|---|---|---|
| Upholstered furniture harmful substances | GB 18584 |
This product must meet the following technical requirements: 1. General furniture mechanical safety: GB/T 3324; 2. Upholstered furniture harmful substances: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
