Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 572 x 610 x 902 mm | |
|---|---|---|
| Seat height | 521 mm | |
| Seat width | 495 mm | |
| Seat depth | 457 mm | |
| Seat cushion thickness | 114 mm | |
| Backrest height above seat | 381 mm | |
| Armrest height above seat | 203 mm | |
| Leg tube diameter | 19 mm | |
| Leg splay angle | 12 degrees | |
| Floor clearance under seat | 267 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 11 kg | |
|---|---|---|
| Static weight capacity | 150 kg | |
| Seat foam density | 45 kg/m³ | |
| FoFoam rebound rate | 55% | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Frame static load test (legs) | 150 kg per leg | |
| Recommended user weight | 120 kg | |
| Color option count | 6 | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Seat and inner back upholstery | Camel brown faux leather, 1.0mm thickness | |
|---|---|---|
| Outer back panel upholstery | Dark brown faux leather, 1.0mm thickness | |
| Seat cushion fill | High-density polyurethane foam, 114mm thickness | |
| Backrest fill | Medium-density polyurethane foam, 50mm thickness | |
| Seat support core | 12mm thick plywood panel | |
| Leg structure | 19mm diameter powder-coated black steel tube, tapered splayed design | |
| Leg frame connection | Reinforced metal mounting plates with M6 hardware | |
| Floor contact pads | Non-marking polyethylene glides | |
| Seam stitching | Bonded polyester thread, 8 stitches per inch | |
| Metal leg finish | Matte black powder coating, rust-resistant pretreatment | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed upright static seating designed for 760mm standard dining table height | |
|---|---|---|
| Arm support | Integrated curved armrests forming wrap-around upper body support for forearms during dining | |
| Floor protection | Non-marking PE glides on leg bases to prevent hardwood/tile scratching and reduce movement noise | |
| Assembly requirement | Knock-down assembly, legs attach to pre-installed seat frame mounting plates with included hardware | |
| Stability feature | Outward splayed legs create wide 520mm front/470mm rear footprint to resist tipping during use | |
| Upholstery maintenance | Smooth faux leather surface wipes clean with soft damp cloth, resists common food and beverage stains for dining use | |
| Back ergonomics | Contoured curved back wraps slightly around torso to provide lateral back support during mealtime seating | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining room | Suitable for use with standard 760mm height dining tables for daily family meals | |
|---|---|---|
| Kitchen breakfast nook | Compact footprint fits small kitchen dining areas and breakfast bar table settings | |
| Cafe and bistro seating | Durable easy-clean upholstery supports high-turnover commercial casual dining use | |
| Home office guest seating | Upright supportive design works as side guest chair next to office desks | |
| Small apartment open-plan living | Sleek tapered leg design takes minimal visual space in compact multi-function rooms | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Domestic furniture - Strength, durability and safety for seating, applies to dining chair performance | |
|---|---|---|
| EN 1022:2018 | Domestic furniture - Seating - Determination of stability, applies to leg splay and tipping resistance |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to internal plywood seat core | |
|---|---|---|
| GB/T 16799-2008 | Furniture use artificial leather, applicable to faux leather upholstery material | |
| GB 28007-2011 | General technical conditions for children's furniture (if used in family dining settings) |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to internal plywood seat core; 2. GB/T 16799-2008: Furniture use artificial leather, applicable to faux leather upholstery material; 3. GB 28007-2011: General technical conditions for children's furniture (if used in family dining settings); Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
