PRODUCT MODULE 01 / 06

Physical Dimensions

Automatic mm / inch conversion · Core engineering specifications

Data source: Structured from factory data; final measured values prevail.

Overall dimensions (W × D × H)	820 × 820 × 835 mm
Overall assembled dimensions	820 x 820 x 835 mm
Seat height	490 mm
Seat depth	580 mm
Seat width	620 mm
Backrest height	420 mm
Armrest height	660 mm
Detachable back pillow dimensions	480 x 400 x 120 mm
Outer shell panel thickness	120 mm
Floor glide diameter	30 mm
Finished Seat Cushion Thickness	90 mm
Backrest Padding Thickness	70 mm
Lumbar Support Zone Height	240 mm
Clear Width Between Armrests	540 mm

PRODUCT MODULE 02 / 06

Weight, Load & Performance

Net weight / load capacity / users / durability

Data source: Product performance data; verify exact test conditions before procurement.

Net weight	40 kg
Recommended static load capacity	181 kg
Seat foam density	45D
Seat foam thickness	120 mm
Backrest padding thickness	80 mm
Upholstery abrasion resistance	50000 Martindale cycles
Seam stitch pitch	30 mm
Foam rebound rate	60%
Warranty period	2 years
Seat Foam Density / Rebound Reference	45 kg/m³ / 65%

PRODUCT MODULE 03 / 06

Materials & Structure

Core acceptance fields · Panels / hardware / frame / upholstery

Data source: Subject to the factory material list and inspection report.

Outer shell upholstery	Dark brown microfiber PU leather with light grey contrast piping
Seat/inner back upholstery	Light grey microfiber PU leather with vertical channel stitching
Detachable pillow upholstery	Matching light grey microfiber PU leather with hidden zipper closure
Inner structural frame	18mm thick plywood + 1.2mm welded steel tube composite frame
Seat padding	High-density polyurethane foam with 20mm soft polyfill top layer
Backrest padding	High-density polyurethane foam with vertical channel tufting inserts
Pillow filling	Shredded memory foam + polyfiber blend
Floor glides	Injection-molded nylon with non-marking felt base
Seat Internal Support Board Thickness	14 mm bent plywood or equivalent support board
Backrest Internal Frame Thickness	14 mm bent plywood/composite reinforced frame
Gas-lift Engineering Specification	Recommended Class 4; outer tube 50 mm; stroke 100 mm
Tilt Mechanism Plate Thickness	2.5 mm cold-rolled steel

PRODUCT MODULE 04 / 06

Functions & Adjustment

Adjustment / rotation / tilt / mobility / storage features

Data source: Functional configuration; the supplier specification prevails.

Seating configuration	Fixed single-occupant upright lounge position with no recline/swivel/rock function
Lumbar support	Detachable matching pillow secured by hidden hook-and-loop fastener to inner back
Floor protection	Four fixed non-swivel glides at base corners to prevent hard floor scratching
Color customization	Supports custom two-tone upholstery combinations for bulk commercial orders
Cushion retention	Fixed seat cushion secured with concealed hook-and-loop strips to prevent shifting
Cleaning access	Removable back pillow cover with hidden zipper for easy spot cleaning
Recline Angle / Lock Reference	125° with 3suggested lock positions
Tilt Tension User-weight Range	Reference adjustment coverage 120 kg
Height Adjustment Stroke	100 mm continuous travel
Rotation / Mobility Configuration	360° swivel with 5-caster multidirectional movement

PRODUCT MODULE 05 / 06

Packaging & Logistics

Verified carton / gross weight / assembly / loading data

Data source: Reference for export quotations and container planning.

Reference Package Count	1 set / 2 cartons
Reference Assembly Time	40 minutes per set
Reference Carton Dimensions	850× 420× 720 mm
Reference Packaged Gross Weight	23 kg/set
Reference Carton Volume	0.26 m³/set
Indicative 20GP Loading	135 sets at 85% space utilization
Indicative 40HQ Loading	320 sets at 85% space utilization

PRODUCT MODULE 06 / 06

Applications & Usage

Recommended spaces / users / usage modes

Data source: Recommended applications based on product form and category.

Residential living room	Suitable for placement next to sofas or in reading nooks for relaxed single-person seating
Office reception area	Ideal for executive lounge or guest waiting spaces for professional visitor seating
Hotel guest room lounge zone	Appropriate for boutique hotel room corner seating to provide upscale relaxed accommodation
High-end retail lounge space	Suitable for luxury store waiting areas to deliver premium customer waiting experience
Private study/office	Works as an auxiliary seating option adjacent to desks for short breaks or guest seating
Recommended Matching Desk Size	2.4 m executive desk
Reference Daily Use Duration	8 hours/day; confirm by ergonomic testing

STANDARD S1

EU Market Entry Requirements * EN Standards

EU Market Access Requirements* EN Standards

EN 12520:2015	Furniture strength, durability and safety for domestic seating, applicable to structural performance validation
EN 1021-1:2014	Upholstered furniture ignitability resistance to smouldering cigarette, applicable to fire safety testing

STANDARD S3

Standards Applicable to China-Market Projects * GB Standards

Standards applicable to China-market projects

GB/T 3324-2017	General technical requirements for wooden furniture, applicable to frame structural safety inspection
GB 20400-2006	Leather and faux leather limit of harmful substances, applicable to upholstery material acceptance
GB/T 10357.3-2013	Furniture mechanical performance test for seating strength and durability, applicable to load testing

Standardized tender description text

This product must meet the following technical requirements:
1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structural safety inspection;
2. GB 20400-2006: Leather and faux leather limit of harmful substances, applicable to upholstery material acceptance;
3. GB/T 10357.3-2013: Furniture mechanical performance test for seating strength and durability, applicable to load testing;
Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.

GENERATED EXPORTS

Ready-to-use export tools

Export data is generated from the current published product record.

Technical Report PDF

Directly download an English report in metric or imperial units.

PDF · UB-LG-CH820-GRBR

Complete Parameter Workbook

Download all product information and parameter modules in English.

XLSX · UB-LG-CH820-GRBR

International Listing Template

English title, specifications, materials, standards and purchasing fields.

XLSX · LISTING

Customs Declaration Data

Prepare customs description, material, usage, dimensions and declaration elements.

CUSTOMS · UB-LG-CH820-GRBROpen Export Tool

Quick Actions

Post an RFQ

Product Description

The Two-Tone Vertical Channel Stitched Barrel Lounge Armchair (model UB-LG-CH820-GRBR) is an unbranded upholstered seating piece defined by a modern light luxury aesthetic. Its silhouette follows a classic wrap-around barrel form, with a dark brown outer shell finished in microfiber PU leather trimmed with light grey contrast piping. The inner seat and back are upholstered in matching light grey microfiber PU leather, accented by crisp vertical channel stitching that adds structured visual texture. A coordinating detachable back pillow sits flush against the inner back, secured with hidden hook-and-loop fasteners to deliver targeted lumbar support without disrupting the chair’s streamlined profile. Its fixed single-occupant design holds an upright lounge position with no recline, swivel, or rock functions, anchored by four fixed non-swivel glides at the base corners. The chair’s construction centers on a durable composite inner frame built from thick plywood and welded steel tube, with a bent plywood internal seat support board to stabilize the seating surface. Padding starts with a core of high-density polyurethane foam across the seat and backrest; the seat includes a soft polyfill top layer for initial comfort, while the backrest integrates vertical channel tufting inserts to maintain its stitched shape over time. The detachable pillow uses a shredded memory foam and polyfiber blend for plush, contouring support. All upholstery is microfiber PU leather, with a hidden zipper on the back pillow cover to enable easy spot cleaning. The base glides feature injection-molded nylon construction with a non-marking felt base to protect hard flooring surfaces, and the fixed seat cushion is secured with concealed hook-and-loop strips to prevent shifting during use. This armchair suits a range of both residential and commercial spaces. In residential settings, it works well placed next to living room sofas, tucked into dedicated reading nooks, or positioned adjacent to private study desks for short breaks or guest seating. In commercial environments, it fits naturally in executive office reception and guest waiting areas, boutique hotel guest room lounge corners, and high-end luxury retail waiting spaces to support a polished, upscale guest experience. For commercial procurement, the product supports custom two-tone upholstery combinations for bulk orders. Buyers should note each unit ships across two cartons, with a straightforward assembly process, and plan space allocation aligned to the chair’s compact barrel footprint, coordinating appropriately with companion pieces such as the recommended executive desk for private office installations.

Two-Tone Vertical Channel Stitched Barrel Lounge Armchair with Detachable Back Pillow Specifications
