Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 660 x 635 x 920 mm | |
|---|---|---|
| Seat height (floor to seat surface) | 460 mm | |
| Seat width (between armrest inner edges) | 480 mm | |
| Seat depth (front edge to backrest face) | 450 mm | |
| Seat cushion thickness | 80 mm | |
| Backrest height (seat surface to top of back) | 470 mm | |
| Armrest height (floor to arm top surface) | 660 mm | |
| Leg tube diameter | 22 mm | |
| Splay leg footprint (distance between outermost leg points) | 540 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight per chair | 8 kg | |
|---|---|---|
| Static weight capacity | 159 kg | |
| Seat foam density | 40 kg/m³ | |
| Foam rebound rate | 60% | |
| Seat upholstery abrasion resistance | 30000 Martindale cycles | |
| Faux leather back surface resistance | Stain-resistant, easy-wipe finish | |
| Powder coat leg finish durability | Scratch and rust resistant for indoor use | |
| Recommended warranty period | 2 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Core acceptance fields · Panels / hardware / frame / upholstery
| Backrest and armrest upholstery | Taupe faux leather (PU) with visible stitched seam details | |
|---|---|---|
| Seat cushion upholstery | Light grey textured woven fabric | |
| Seat cushion fill | High-density polyurethane foam over supportive webbing base | |
| Backrest fill | Medium-density polyurethane foam padded under faux leather | |
| Internal frame | 18 mm thick engineered plywood seat and back support | |
| Legs | 1.2 mm thick matte black powder-coated tapered steel tubes | |
| Floor contact points | Non-marking plastic glide caps affixed to leg bases | |
| Upholstery stitching | 8 stitches per inch seam pitch | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Structural configuration | Fixed non-swivel, non-reclining, non-height-adjustable rigid frame | |
|---|---|---|
| Backrest support | Curved wrap-around back with mid-level open cutout for lower back ventilation | |
| Armrest function | Continuous integrated armrests extending from back frame to support forearms during dining | |
| Stability feature | Four slightly outward-splayed tapered legs distribute weight to reduce tipping risk | |
| Floor protection | Non-abrasive glides on leg bases prevent hard floor scratching and reduce movement noise | |
| Assembly requirement | Knock-down assembly with included hardware attaching legs to pre-upholstered seat frame | |
| Cleaning compatibility | Wipe-clean faux leather back/arms and removable fabric seat cushion allow simple maintenance | |
| Fit compatibility | Designed to slide fully under standard 750 mm height dining tables with standard apron clearance | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining space | Suitable for home dining rooms paired with standard 750 mm height dining tables | |
|---|---|---|
| Kitchen breakfast nook | Compact footprint fits small kitchen dining areas without occupying excess floor space | |
| Commercial hospitality use | Suitable for cafes, boutique restaurants and hotel guest dining areas | |
| Home office guest seating | Can be used as side seating in home offices for short-term visitor use | |
| Reception waiting areas | Appropriate for light-traffic office or salon reception waiting zones | |
| Recommended table pairing | Pairs with dining tables with minimum 680 mm apron clearance to accommodate armrest height | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Furniture stability recommendation | EN 12521:2015 (Furniture – Strength, durability and safety for domestic seating) |
|---|
Standards applicable to China-market projects
| Upholstery material safety recommendation | GB 18401(National general safety technical code for textile products, Class B direct skin contact) | |
|---|---|---|
| Metal finish recommendation | GB/T 3325(Metal furniture general technical requirements, coating adhesion and corrosion resistance) |
This product must meet the following technical requirements: 1. Upholstery material safety recommendation: GB 18401(National general safety technical code for textile products, Class B direct skin contact); 2. Metal finish recommendation: GB/T 3325(Metal furniture general technical requirements, coating adhesion and corrosion resistance); Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
