| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 620 x 600 x 760 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Product net weight | 12 kg | |
|---|---|---|
| Maximum static seat load | 150 kg | |
| Seat foam density | 35 kg/m³ | |
| Backrest static load rating | 75 kg | |
| Outdoor UV exposure resistance | 1000 hours | |
| Warranty period | 2 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles | |
| Five-star Base Static Load Reference | Acceptance target ≥120 kg; chair reference load 150 kg |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural frame | 18mm diameter polished chrome-plated tubular steel | |
|---|---|---|
| Seat cushion core | High resilience polyurethane foam | |
| Seat upholstery | Solution-dyed woven performance fabric | |
| Back support surface | Woven weather-resistant resin mesh | |
| Armrests | Continuous bent tubular steel matching main frame | |
| Frame foot pads | Non-slip polyethylene glides | |
| Seat base support | Powder-coated steel inner ring under cushion | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel | |
| Five-star Base Material Thickness | Metal base wall 3.5 mm; diameter 700 mm |
Adjustment / rotation / tilt / mobility / storage features
| Seating support | Fixed-position deep rounded seat for relaxed upright or slightly reclined seating | |
|---|---|---|
| Back support | Semi-flexible woven central back panel that conforms slightly to user posture | |
| Arm support | Full looped curved armrests at ergonomic height for forearm rest | |
| Floor protection | Integrated plastic glides at each frame contact point to prevent hard floor damage | |
| Weather suitability | Corrosion-resistant metal finish and quick-drying back material for covered outdoor use | |
| Cushion retention | Recessed frame lip holds seat cushion securely in place to prevent sliding | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Covered outdoor patio | Suitable for residential balconies, verandas and terraces with overhead weather protection | |
|---|---|---|
| Modern indoor lounge space | Fits minimalist living rooms, reading nooks and boutique waiting areas | |
| Hospitality casual seating | Appropriate for hotel lobbies, cafe outdoor zones and co-working breakout areas | |
| Poolside relaxation area | Usable in shaded pool deck zones away from direct constant water splash | |
| Pairing recommendation | Works with matching low round side tables for coordinated seating sets | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
US and Canada office-furniture standards
| North America procurement and testing reference | Recommended references: ANSI/BIFMA X5.4 |
|---|
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
