Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 860 × 780 × 940 mm | |
|---|---|---|
| Seat height | 510 mm | |
| Seat width | 640 mm | |
| Seat depth | 700 mm | |
| Seat cushion thickness | 250 mm | |
| Backrest height above seat | 560 mm | |
| Armrest height above seat | 170 mm | |
| Leg height | 210 mm | |
| Backrest thickness | 80 mm | |
| Armrest width | 140 mm | |
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended static load capacity | 150 kg | |
|---|---|---|
| Net weight per unit | 18 kg | |
| Seat foam density | 45 kg/m³ | |
| Seat foam resilience | 55% | |
| Seat support spring gauge | 3.6 mm | |
| Recommended user count | 1 | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Spare parts availability period | 2 years | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Front seat/back/inner arm upholstery | Cream/beige PU faux leather | |
|---|---|---|
| Outer side panel upholstery | Brown PU faux leather | |
| Seam trim | Black contrast piping | |
| Seat and back padding | High-density polyurethane foam | |
| Seat support structure | High-gauge sinuous S-springs | |
| Inner structural frame | 15mm thick plywood and rubberwood | |
| Support legs | 30mm diameter black powder-coated tapered metal | |
| Leg finish | Matte black eco-friendly paint | |
| Frame joint hardware | Zinc-plated steel screws and brackets | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly requirement | Knock-down leg attachment with included hardware | |
|---|---|---|
| Seating posture | Relaxed semi-reclined position for casual lounging | |
| Arm support | Continuous upholstered armrests integrated with backrest | |
| Cleaning method | Wipe clean with damp soft cloth | |
| Adjustment features | No recline, swivel, or height adjustment mechanisms | |
| Mobility | Stationary fixed placement with non-marking foot glides | |
| Structural stability | Four splayed legs with 780mm footprint for tip resistance | |
| Seam construction | 8 stitches per 30mm reinforced seam stitching | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Living room application | Occasional accent seating next to sofa or coffee table | |
|---|---|---|
| Reception area application | Guest seating in office reception or waiting zones | |
| Bedroom application | Reading chair placed in bedroom corner or dressing area | |
| Hotel lounge application | Guest room or hotel lobby lounge seating | |
| Recommended pairing | Matches with small round side tables 550 mm in height | |
| Floor protection | Suitable for hard flooring with included non-marking glides | |
| Style fit | Complements mid-century modern and contemporary interior schemes | |
| Recommended Matching Desk Size | 2.4 m executive desk |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12520:2015 | Strength, durability and safety requirements for domestic seating | |
|---|---|---|
| EN 1021-1:2014 | Upholstered furniture flammability cigarette ignition resistance | |
| EN 13356:2019 | Anti-slip foot glide performance requirements for stationary furniture |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to frame structure | |
|---|---|---|
| GB 20400-2006 | Leather and faux leather limit of harmful substances, applicable to upholstery | |
| GB/T 1952.1-2012 | Stability and strength test methods for upholstered seating |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to frame structure; 2. GB 20400-2006: Leather and faux leather limit of harmful substances, applicable to upholstery; 3. GB/T 1952.1-2012: Stability and strength test methods for upholstered seating; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
