Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 620 x 580 x 820 mm | |
|---|---|---|
| Finished Seat Cushion Thickness | 90 mm | |
| Backrest Padding Thickness | 70 mm | |
| Lumbar Support Zone Height | 240 mm | |
| Clear Width Between Armrests | 540 mm |
Net weight / load capacity / users / durability
| Net weight | 12 kg | |
|---|---|---|
| Static seat load capacity | 150 kg | |
| Seat foam density | 35 kg/m³ | |
| Back foam thickness | 50 mm | |
| Seat foam thickness | 80 mm | |
| Upholstery abrasion resistance | 50000 Martindale cycles | |
| Floor protection rating | Non-marking plastic glides, 20 mm diameter | |
| Seat Foam Density / Rebound Reference | 45 kg/m³ / 65% | |
| Back Foam Density Reference | 38 kg/m³ | |
| Upholstery Thickness / Abrasion Reference | 1.4 mm / 50000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Structural frame | Solid ash wood with walnut stain finish | |
|---|---|---|
| Seat cushion core | High-density polyurethane foam | |
| Back cushion core | Medium-density polyurethane foam | |
| Upholstery surface | Faux leather (PU) in slate blue | |
| Armrest construction | Bent solid wood with polished lacquer topcoat | |
| Seat support base | 12 mm thick plywood webbed support panel | |
| Foot glides | Black injection-molded nylon | |
| Frame joinery | Mortise and tenon wood joints with reinforced adhesive | |
| Seat Internal Support Board Thickness | 14 mm bent plywood or equivalent support board | |
| Backrest Internal Frame Thickness | 14 mm bent plywood/composite reinforced frame | |
| Gas-lift Engineering Specification | Recommended Class 4; outer tube 50 mm; stroke 100 mm | |
| Tilt Mechanism Plate Thickness | 2.5 mm cold-rolled steel |
Adjustment / rotation / tilt / mobility / storage features
| Seating function | Fixed position upholstered armchair for lounge and dining use | |
|---|---|---|
| Back support | Curved ergonomic back with 12 degree recline angle | |
| Arm support | Continuous curved armrests integrated with leg structure | |
| Floor protection | Replaceable nylon glides at each leg base | |
| Assembly requirement | Minimal assembly required, legs attach to pre-built seat frame | |
| Cleaning access | Smooth upholstery surface allows wipe-clean maintenance | |
| Recline Angle / Lock Reference | 125° with 3suggested lock positions | |
| Tilt Tension User-weight Range | Reference adjustment coverage 120 kg | |
| Height Adjustment Stroke | 100 mm continuous travel | |
| Rotation / Mobility Configuration | 360° swivel with 5-caster multidirectional movement |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Carton Dimensions | 850× 420× 720 mm | |
| Reference Packaged Gross Weight | 23 kg/set | |
| Reference Carton Volume | 0.26 m³/set | |
| Indicative 20GP Loading | 135 sets at 85% space utilization | |
| Indicative 40HQ Loading | 320 sets at 85% space utilization |
Recommended spaces / users / usage modes
| Residential dining space | Used as a dining armchair around matching wood dining tables | |
|---|---|---|
| Home lounge and living areas | Placed in living rooms or reading nooks for casual seating | |
| Commercial reception areas | Used in office lobbies, boutique cafes and hotel guest areas | |
| Hospitality guest rooms | Placed as accent seating in hotel bedrooms or lounge suites | |
| Co-working break areas | Used in casual break zones for short-term relaxed seating | |
| Color customization | Available in multiple upholstery and wood finish options | |
| Recommended Matching Desk Size | 2.4 m executive desk | |
| Reference Daily Use Duration | 8 hours/day; confirm by ergonomic testing |
EU Market Access Requirements* EN Standards
| Seating strength and durability | EN 12520:2015 | |
|---|---|---|
| Upholstery flame retardancy | EN 1021:2014 | |
| Formaldehyde emission | EN 13986:2004 |
Standards applicable to China-market projects
| Frame structural stability | GB/T 3324 | |
|---|---|---|
| Upholstery durability | GB/T 2012 | |
| Formaldehyde emission | GB 18584 |
This product must meet the following technical requirements: 1. Frame structural stability: GB/T 3324; 2. Upholstery durability: GB/T 2012; 3. Formaldehyde emission: GB 18584; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
