PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2400 × 900 × 750 mm | |
|---|---|---|
| Sintered stone tabletop thickness | 12 mm | |
| Acrylic support panel thickness | 20 mm | |
| Seating knee clearance height | 690 mm | |
| Table corner radius | 5 mm | |
| Support panel width (end panels) | 600 mm | |
| Clear floor space under table | 2200 x 800 mm | |
| Tabletop overhang past supports | 100 mm | |
| Anti-slip foot pad thickness | 5 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop static load capacity | 300 kg | |
|---|---|---|
| Table net weight | 95 kg | |
| Sintered stone surface Mohs hardness | 7 | |
| Maximum short-duration contact temperature | 100 °C | |
| Seating capacity | 8 people | |
| Acrylic support light transmittance | 92% | |
| Surface stain resistance rating | Non-porous, zero liquid penetration | |
| Recommended product warranty period | 36 months | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface layer | Matte marble-patterned sintered stone | |
|---|---|---|
| Tabletop backing substrate | 15mm multi-layer solid wood board | |
| Support structures | High-clarity transparent cast acrylic (PMMA) | |
| Connection hardware | Zinc-plated steel locking brackets | |
| Foot protection pads | Non-marking nitrile rubber pads | |
| Table edge finish | Fine polished seamless edge | |
| Acrylic surface finish | Diamond-polished clear finish | |
| Material moisture content (wood substrate) | 10% | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Support design function | Double end-panel cantilever acrylic supports | |
|---|---|---|
| Floor protection function | Replaceable anti-slip rubber feet | |
| Surface cleaning function | Non-porous sintered stone surface | |
| Structural stability feature | Evenly distributed metal lock connectors | |
| Assembly requirement | Flat-pack assembly required | |
| Customization compatibility | Accepts custom size/edge drop options | |
| Heat resistance function | Heat-resistant tabletop surface | |
| Visual design feature | Fully transparent support structure | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room use | Large open-plan dining spaces | |
|---|---|---|
| Modern minimalist interiors | Wabi-sabi, light luxury, contemporary design schemes | |
| Open-plan kitchen island extension | Adjacent to kitchen islands as extended casual dining surface | |
| Small commercial cafe/restaurant use | High-end boutique dining venues | |
| Showroom/design studio use | Furniture display and client meeting spaces | |
| Hard flooring environments | Concrete, tile, terrazzo and wood flooring |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture surface durability | EN 15187:2006 | |
|---|---|---|
| Table structural performance | EN 12521:2015 | |
| Formaldehyde emissions | EN 13986:2004+A1:2015 |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop surface safety | GB/T 3810.3 | |
|---|---|---|
| Formaldehyde emission (substrate) | GB 18580 | |
| Structural stability for furniture | GB/T 10357.1 | |
| Acrylic material safety | GB/T 7134 |
Standardized tender description text
This product must meet the following technical requirements: 1. Tabletop surface safety: GB/T 3810.3; 2. Formaldehyde emission (substrate): GB 18580; 3. Structural stability for furniture: GB/T 10357.1; 4. Acrylic material safety: GB/T 7134; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
