PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 900 × 750 mm | |
|---|---|---|
| tabletop thickness | 12 mm | |
| leg section size | 30 x 30 mm | |
| leg wall thickness | 1.2 mm | |
| under-table knee clearance height | 710 mm | |
| leg inset from table corners | 100 mm | |
| table edge overhang beyond leg line | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| net product weight | 65 kg | |
|---|---|---|
| distributed tabletop static load | 150 kg | |
| point load capacity at center | 50 kg | |
| tabletop surface Mohs hardness | 7 | |
| surface heat resistance | 180 °C | |
| leg base static stability load | 200 kg | |
| warranty period | 3 years | |
| seating capacity clearance per seat | 600 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop slab | 12mm white marble-vein sintered stone, polished smooth finish | |
|---|---|---|
| tabletop backing | 15mm honeycomb composite reinforcement | |
| leg construction | Matte black powder-coated carbon steel tubing, splayed profile | |
| leg foot pads | 8mm diameter non-slip adjustable plastic glides | |
| connection hardware | M8 zinc-plated steel bolts and lock washers | |
| surface coating on legs | 60μm matte black powder coat, scratch-resistant finish | |
| edge treatment | 45-degree chamfered polished edge on tabletop perimeter | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| height adjustability | Fixed 750mm dining height, no lift mechanism | |
|---|---|---|
| extendable function | Fixed size, no integrated leaf extension mechanism | |
| leveling adjustment | 10mm vertical adjustment range via foot glides for uneven floors | |
| cleaning compatibility | Non-porous tabletop wipes clean with damp soft cloth, no sealant required | |
| surface scratch resistance | Resists cutlery scratches from daily dining use | |
| assembly requirement | Knock-down assembly, legs attach to underside of pre-drilled top | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential dining room | Seats 6 diners for daily family meals and small gatherings | |
|---|---|---|
| apartment open-plan dining area | Slim profile and minimalist finish suits compact modern living spaces | |
| small restaurant bistro seating | Durable easy-clean surface fits high-turnover casual dining settings | |
| home office multipurpose surface | Flat stable top can serve as shared workspace for laptop and paperwork | |
| recommended pairing | Matches armless upholstered dining chairs with slim metal legs |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 15185:2011 | Test for resistance to abrasion of furniture surfaces, for tabletop finish |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for structural stability checks | |
|---|---|---|
| GB/T 4893.1-2021 | Furniture surface test for resistance to cold liquids, valid for tabletop finish | |
| GB/T 10357.1-2013 | Furniture mechanical test for table strength and stability |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for structural stability checks; 2. GB/T 4893.1-2021: Furniture surface test for resistance to cold liquids, valid for tabletop finish; 3. GB/T 10357.1-2013: Furniture mechanical test for table strength and stability; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
