Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2800 × 1400 × 760 mm | |
|---|---|---|
| Tabletop thickness | 40 mm | |
| Pedestal leg diameter | 220 mm | |
| Pedestal leg height | 720 mm | |
| Seating clearance per place setting | 600 mm | |
| Under-table knee clearance height | 680 mm | |
| Edge radius (soft organic edge) | 20 mm | |
| Pedestal leg spacing (long axis) | 1200 mm | |
| Pedestal leg spacing (short axis) | 700 mm | |
| Overhang (long end from outermost leg) | 500 mm | |
| Overhang (short side from center leg) | 350 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop static load capacity | 300 kg | |
|---|---|---|
| Product net weight | 320 kg | |
| Recommended seating capacity | 6 persons | |
| Surface abrasion resistance (sealed marble) | 4000 cycles | |
| Leg assembly static load rating (per pedestal) | 150 kg | |
| Residential service life | 10 years | |
| Tabletop moisture resistance (sealed surface) | Grade B | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | Polished natural marble with sealed glossy finish | |
|---|---|---|
| Pedestal legs | Thick-walled steel tubing with brushed brass bronze finish | |
| Internal support frame | Powder-coated steel cross-bracing under tabletop | |
| Mounting hardware | Stainless steel M10 anchor bolts with anti-corrosion coating | |
| Floor protection pads | 5mm thick non-slip felt pads under each pedestal base | |
| Tabletop edge finish | Hand-polished rounded bevel, 2mm edge sealer coat | |
| Surface protective coating | Food-safe penetrating stone sealer | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Support structure | Triangular three-pedestal fixed base | |
|---|---|---|
| Tabletop functionality | Smooth non-porous sealed surface | |
| Assembly requirement | Knock-down leg attachment to pre-installed top brackets | |
| Floor compatibility | Leveling adjustable felt glides on each pedestal base | |
| Seating layout support | Accommodates 2 armchairs at each long end and 1 per side | |
| Surface maintenance | Sealed marble finish supports regular wiping with neutral cleaners | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Suitable for open-plan or formal dining spaces in luxury homes and villas | |
|---|---|---|
| High-end hospitality spaces | Applicable for private dining rooms in boutique hotels and upscale restaurants | |
| Show home and model apartment staging | Ideal for luxury real estate showcase interiors | |
| Recommended pairing | Pairs with velvet-upholstered brass-frame dining armchairs | |
| Space requirement | Minimum room size 4000 x 3600 mm |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture: Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 15186:2006 | Furniture: Test methods for surface resistance to abrasion |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden and stone household furniture | |
|---|---|---|
| GB 6566-2010 | Limit of radionuclides in building decoration materials | |
| GB/T 4893.9-2013 | Furniture surface test: Resistance to hot and cold cycles |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden and stone household furniture; 2. GB 6566-2010: Limit of radionuclides in building decoration materials; 3. GB/T 4893.9-2013: Furniture surface test: Resistance to hot and cold cycles; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
