Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 760 mm | |
|---|---|---|
| Overall table dimensions | 1350 x 1350 x 760 mm | |
| Tabletop thickness | 18 mm | |
| Central lazy susan diameter | 800 mm | |
| Lazy susan thickness | 12 mm | |
| Pedestal base maximum footprint diameter | 680 mm | |
| Knee clearance height under tabletop | 670 mm | |
| Black vertical accent panel height | 620 mm | |
| Base foot contact width per side | 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 300 kg | |
|---|---|---|
| Seating capacity | 6 people | |
| Table net weight | 85 kg | |
| Base stability tilt load | 80 kg | |
| Surface scratch resistance | 6 Mohs | |
| Metal base corrosion resistance rating | Grade 48h neutral salt spray | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop slab | Polished light white/light gray sintered stone, food-safe non-porous surface | |
|---|---|---|
| Lazy susan slab | Matching polished sintered stone, smooth rounded edge | |
| Pedestal main frame | 1.5mm thick polished 304 stainless steel, mirror finish | |
| Vertical accent panels | High-gloss black lacquered MDF panels, 18mm thick | |
| Flared base foot pads | 3mm thick non-slip rubber pads under stainless steel feet | |
| Lazy susan rotating bearing | Zinc alloy 360° swivel bearing with 6 nylon support rollers | |
| Tabletop support backing | 15mm thick plywood reinforcement board under stone slab | |
| Assembly hardware | M8 stainless steel hex bolts with lock washers | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy susan rotation | 360° smooth manual rotation with stop-free motion, enabled by central roller bearing | |
|---|---|---|
| Pedestal leg design | Single central sculptural pedestal with no perimeter legs, eliminating obstructions for seating | |
| Tabletop edge treatment | 1/4 rounded polished edge on tabletop and lazy susan for safe dining use | |
| Surface maintenance | Non-porous sintered stone surface resists stains and allows direct food contact, wipe-clean design | |
| Floor protection | Rubber foot pads prevent floor scratching and reduce movement during use | |
| Assembly structure | Knock-down design with separate tabletop, pedestal and lazy susan components for flat-pack shipping | |
| Seating accessibility | Even 600mm per-person perimeter space allows 6 diners to sit without leg interference | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | Suitable for modern and light luxury home interiors seating 6diners for daily meals | |
|---|---|---|
| Apartment small dining areas | Compact 1.35m round footprint fits open-plan kitchen and dining spaces without wasted space | |
| Small restaurant private dining rooms | Durable easy-clean stone surface supports light commercial use for casual dining venues | |
| Showroom and model home staging | Contemporary sculptural base and neutral finish complements luxury interior display schemes | |
| Open-plan living spaces | Round shape eliminates sharp corners, safe for family use in combined living/dining zones | |
| Hospitality lounge areas | Polished metal base and stain-resistant top suit upscale hotel lounge dining configurations |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture strength and durability test methods for table surfaces | |
| EN 10088-2:2014 | Stainless steel sheet material specifications for polished structural components |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF accent panel structural integrity | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard/MDF performance requirements, applicable to backing and panel components | |
| GB 6566-2010 | Radionuclide limits for decorative stone materials, applicable to sintered stone/marble tabletops | |
| GB/T 19001-2016 | Quality management system guidance for consistent furniture production |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF accent panel structural integrity; 2. GB/T 4897.3-2015: Particleboard/MDF performance requirements, applicable to backing and panel components; 3. GB 6566-2010: Radionuclide limits for decorative stone materials, applicable to sintered stone/marble tabletops; 4. GB/T 19001-2016: Quality management system guidance for consistent furniture production; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
