Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1500 × 1500 × 750 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Circular floor base plate diameter | 710 mm | |
| Pedestal column height | 690 mm | |
| Pedestal column top width | 220 mm | |
| Pedestal column bottom width | 380 mm | |
| Under-table knee clearance height | 670 mm | |
| Tabletop edge overhang from base edge | 395 mm | |
| Base plate thickness | 8 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net product weight | 68 kg | |
|---|---|---|
| Static distributed tabletop load capacity | 136 kg | |
| Recommended seating capacity | 6 people | |
| Powder coat finish abrasion resistance | Grade 2, 2000 cycles | |
| Stone top heat resistance | 1200 °C | |
| Table stability lateral load rating | 15 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface layer | 20mm sintered stone with matte white marble-vein finish | |
|---|---|---|
| Tabletop underpanel reinforcement | 15mm multi-layer plywood substrate | |
| Central pedestal column | 2mm thick matte black powder-coated carbon steel, faceted tapered design | |
| Floor contact base plate | 8mm thick matte black powder-coated carbon steel circular plate | |
| Tabletop-to-pedestal connection brackets | 3mm thick black powder-coated steel triangular support brackets | |
| Base plate floor protection | 5mm thick non-slip EVA rubber pads affixed to base underside | |
| Assembly hardware | Grade 8.8 zinc-plated steel bolts and lock washers | |
| Edge finish | Hand-polished beveled rounded edge on tabletop | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly requirement | Knock-down assembly with three main components: tabletop, pedestal, base plate | |
|---|---|---|
| Seating access | Unobstructed perimeter legroom with no corner legs to block chair movement | |
| Surface functionality | Stain-resistant, scratch-resistant non-porous tabletop suitable for daily meal service | |
| Floor protection | Non-slip rubber pads prevent floor scratches and reduce table movement during use | |
| Weight distribution | Wide circular base plate disperses load evenly to prevent floor indentation | |
| Cleaning access | Smooth pedestal and base surfaces allow full under-table cleaning access | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | Suitable for 6person family meals in modern, minimalist or light luxury interiors | |
|---|---|---|
| Open-plan kitchen dining zones | Compact pedestal footprint fits smaller open living spaces without blocking walkways | |
| Small cafe and restaurant seating | Durable stone surface and stable base support light commercial hospitality use | |
| Apartment and condominium units | Space-efficient design provides adequate seating without protruding corner legs | |
| Show home and model unit staging | High-contrast two-tone finish works as a focal point for contemporary interior staging |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for residential dining tables | |
|---|---|---|
| EN 1022:2018 | Stability test method for domestic seating and tables | |
| EN 15185:2011 | Abrasion resistance test for furniture surface finishes |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to plywood substrate components | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test method for furniture finishes, applicable to tabletop coating | |
| GB/T 17657-2013 | Test methods for wood-based panels, applicable to plywood underpanel performance | |
| GB 6675-2014 | Furniture edge and tip safety requirements, applicable to tabletop edge treatment |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to plywood substrate components; 2. GB/T 4893.4-2013: Surface abrasion resistance test method for furniture finishes, applicable to tabletop coating; 3. GB/T 17657-2013: Test methods for wood-based panels, applicable to plywood underpanel performance; 4. GB 6675-2014: Furniture edge and tip safety requirements, applicable to tabletop edge treatment; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
