Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2200 × 1100 × 760 mm | |
|---|---|---|
| Tabletop thickness | 36 mm | |
| Leg section size | 80 x 80 mm square tube | |
| Leg wall thickness | 1.5 mm | |
| Under-table knee clearance height | 700 mm | |
| End leg setback from table edge | 100 mm | |
| Long side seating clearance | 2000 mm | |
| Footprint width per leg frame | 700 mm | |
| Edge profile overhang | 50 mm | |
| Floor to leg crossbar clearance | 120 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total unit weight | 160 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 250 kg | |
| Seating capacity | 8 people | |
| Surface scratch resistance | Grade 3 | |
| Surface heat resistance | 180 °C | |
| Stainless steel polish durability | 500 cleaning cycles | |
| Structural joint static load rating | 120 kg per leg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface layer | Polished natural marble-patterned stone slab with high-gloss finish | |
|---|---|---|
| Tabletop support substrate | 18 mm thick high-density moisture-resistant MDF backing | |
| Leg frame material | 201 grade stainless steel with 8K mirror polish | |
| Frame welding treatment | Seamless ground and polished weld joints at tube intersections | |
| Foot glides | Adjustable nylon floor glides with 10 mm adjustment range | |
| Connection hardware | M8 zinc-plated steel hex bolts with lock washers | |
| Stone edge finish | Flat polished straight edge with 1 mm eased radius | |
| Under-table bracing | 1.2 mm thick stainless steel cross braces between U-leg uprights | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Assembly structure | Knock-down flat-pack design requiring top-to-base bolted attachment | |
|---|---|---|
| Leveling adjustment | Adjustable foot glides compensate for 10 mm floor unevenness | |
| Surface maintenance | Non-porous glossy surface allows wipe-clean removal of food and liquid spills | |
| Seating accessibility | Open U-leg design creates unobstructed perimeter clearance for dining chairs | |
| Extension mechanism | Fixed non-extendable tabletop with no built-in leaf storage | |
| Corrosion resistance | Mirror-polished stainless steel resists daily household moisture and cleaning agents | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Serves 8diners in modern minimalist, luxury or light-contemporary home interiors | |
|---|---|---|
| Open-plan kitchen dining area | Open leg design maintains visual lightness while supporting frequent daily meal use | |
| Small corporate hospitality lounge | Provides elevated dining surface for guest refreshments and small meeting gatherings | |
| Apartment open living space | Rectangular form fits well against long walls or as central room feature piece | |
| Furniture showroom display | Works as centerpiece display paired with upholstered dining chairs and matching sideboards | |
| Recommended pairing | Use with armless upholstered dining chairs 450mm seat height to match 760mm table height |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 1730:2000 | Test methods for table stability, strength and durability validation | |
| EN 13722:2004 | Assessment of furniture surface resistance to cold liquids for dining use |
STANDARD S2
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Desk products standard, reference for horizontal surface load and stability testing |
|---|
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applies to stone-topped dining table backing structure | |
|---|---|---|
| GB/T 4893.4-2021 | Surface film adhesion test method for furniture finish, applicable to stone top coating assessment | |
| GB 28007-2011 | Furniture structural safety specification for children use, applies to sharp edge and stability checks |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applies to stone-topped dining table backing structure; 2. GB/T 4893.4-2021: Surface film adhesion test method for furniture finish, applicable to stone top coating assessment; 3. GB 28007-2011: Furniture structural safety specification for children use, applies to sharp edge and stability checks; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
