Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 910 × 1600 × 760 mm | |
|---|---|---|
| Overall assembled dimensions | 1600 x 910 x 760 mm | |
| Tabletop thickness | 25 mm | |
| Tabletop corner radius | 50 mm | |
| Under-table knee clearance height | 690 mm | |
| Sled leg vertical bar width | 50 mm | |
| Sled base floor contact length | 620 mm | |
| Clearance between two sled leg assemblies | 900 mm | |
| Tabletop edge overhang past leg frame | 80 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Assembled net weight | 55 kg | |
|---|---|---|
| Distributed static tabletop load | 82 kg | |
| Seating capacity | 4 people | |
| Adjustable foot pad height adjustment | 10 mm | |
| Metal frame static load capacity | 200 kg | |
| Finish corrosion resistance salt spray rating | 48 hours | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm high-density particleboard core | |
|---|---|---|
| Tabletop surface layer | Black marble-patterned faux marble laminate | |
| Tabletop edge finish | PVC edge banding matching black finish | |
| Leg frame material | 1.5mm thick carbon steel tubing | |
| Leg surface finish | Electroplated brushed gold finish | |
| Foot pads | Non-marking PP plastic adjustable glides | |
| Frame connecting hardware | Zinc-plated steel M8 bolts and cross dowels | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Floor leveling system | Rotating adjustable foot pads at each leg base | |
|---|---|---|
| Seating configuration | Two seats per long side, no end-seat obstruction | |
| Surface stain resistance | Non-porous high-gloss top coating | |
| Knock-down assembly design | Two leg assemblies attached to tabletop via included hardware | |
| Floor protection | Soft non-marking foot pads | |
| Stability performance | Two wide U-shaped sled bases at opposite table ends | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Seats 4 for daily family meals in apartment or small home dining areas | |
|---|---|---|
| Open-plan kitchen dining nook | Compact footprint fits kitchen island adjacent seating zones | |
| Small apartment breakfast area | Narrow 910mm depth fits tight spaces without blocking walkways | |
| Rental property furnishing | Durable wipe-clean surface and stable frame suit high-turnover residential use | |
| Complementary pairing | Pairs with upholstered dining chairs with 450mm seat height for ergonomic dining posture |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Strength, durability and safety requirements for domestic dining tables | |
|---|---|---|
| EN 1022:2018 | Stability test methods for domestic seating and tables | |
| EN 13722:2004 | Test methods for furniture surface finish durability |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to tabletop substrate quality | |
|---|---|---|
| GB/T 4893.1-2021 | Surface wear resistance test method for furniture coatings, applicable to tabletop finish | |
| GB/T 17657-2013 | Test methods for wood-based panels, applicable to substrate physical performance |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to tabletop substrate quality; 2. GB/T 4893.1-2021: Surface wear resistance test method for furniture coatings, applicable to tabletop finish; 3. GB/T 17657-2013: Test methods for wood-based panels, applicable to substrate physical performance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
