PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 750 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Central lazy susan diameter | 800 mm | |
| Pedestal base diameter (floor contact) | 720 mm | |
| Underside knee clearance to floor | 695 mm | |
| Pedestal column wall thickness | 1.5 mm | |
| Lazy susan tray thickness | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 150 kg | |
|---|---|---|
| Lazy susan rotation cycle rating | 30000 cycles | |
| Tabletop surface Mohs hardness | 6 | |
| Instant tabletop heat resistance | 300 °C | |
| Tabletop water absorption rate | 0.05 % | |
| Anti-tip stability load (edge load) | 30 kg | |
| Warranty period for structural components | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main tabletop | 20mm polished white sintered stone | |
|---|---|---|
| Structural underlay | ENF-grade solid wood core board | |
| Conical pedestal base | Polished 304 stainless steel | |
| Lazy susan tray | Matching white sintered stone | |
| Lazy susan bearing | Stainless steel ball bearing assembly | |
| Connection hardware | Zinc-plated steel M10 mounting bolts | |
| Base floor contact pads | Non-slip rubber pads | |
| Surface finish | High-gloss polished coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy susan rotation | 360-degree unobstructed rotation with ball bearing | |
|---|---|---|
| Assembly requirement | Knock-down assembly, attach pedestal to tabletop with included hardware | |
| Surface maintenance | Wipe clean with soft damp cloth | |
| Lazy susan removability | Tray lifts off for separate cleaning | |
| Stability design | Wide flared pedestal base with weighted floor contact | |
| Seating accommodation | Supports up to 6 standard dining chairs around perimeter | |
| Lazy susan rotation bearing diameter | 300 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Note | All values are procurement engineering s, not supplier-measured data | |
|---|---|---|
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Fits open-plan dining areas with 2.8m+ ceiling height, paired with 6dining chairs | |
|---|---|---|
| Luxury apartment interior | Matches light neutral modern interior finishes for premium home settings | |
| Casual private dining space | Suitable for small private restaurant booths with seated meal service | |
| Open kitchen dining zone | Aligns with standard kitchen counter height for adjacent meal preparation | |
| Recommended pairing | Upholstered dining chairs with 450mm seat height for ergonomic dining posture |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture safety standard | EN 12521:2015 | |
|---|---|---|
| Furniture surface resistance standard | EN 15186:2012 |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Furniture general technical standard | GB/T 3324 | |
|---|---|---|
| Formaldehyde emission limit | GB 18584 | |
| Surface physical and chemical test standard | GB/T 4893.4 |
Standardized tender description text
This product must meet the following technical requirements: 1. Furniture general technical standard: GB/T 3324; 2. Formaldehyde emission limit: GB 18584; 3. Surface physical and chemical test standard: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
