Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 2000 x 1000 x 770 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Under-table knee clearance height | 680 mm | |
| X-base cross leg tube section | 80 x 40 mm | |
| Floor support plate dimensions | 1200 x 600 mm | |
| Metal base wall thickness | 2 mm | |
| Tabletop overhang per long side | 100 mm | |
| Tabletop edge radius | 2 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Total table weight | 150 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 136 kg | |
| Maximum seating capacity | 8 people | |
| Tabletop surface heat resistance | 1200 °C | |
| Surface scratch resistance (Mohs hardness) | 7 | |
| Manufacturer warranty period | 1 year | |
| Available finish color count | 6 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop panel | 12mm glossy polished sintered stone, AAA grade with subtle light veining | |
|---|---|---|
| Tabletop backing layer | 10mm honeycomb aluminum reinforcement | |
| X-cross support frame | Brushed gold titanium-coated stainless steel tubes, welded joints | |
| Floor contact base plate | Flat brushed gold stainless steel plate, polished edge | |
| Tabletop connection hardware | M10 stainless steel mounting bolts with anti-loosening lock washers | |
| Surface finish coating (metal) | 15μm thick PVD titanium gold plating, anti-tarnish treatment | |
| Floor protection pads | 5mm thick non-slip EVA rubber pads under base plate | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Tabletop configuration | Fixed non-extendable rectangular top, no built-in leaf mechanism | |
|---|---|---|
| Base stability design | Intersecting X-frame connected to full-width floor plate to prevent wobble | |
| Surface cleanability | Non-porous polished surface supports wipe-clean with common household cleaners | |
| Floor protection | Soft rubber contact pads prevent scratching of hard polished flooring | |
| Assembly requirement | Knock-down assembly required, connecting top to base with included hardware | |
| Load distribution | Central X-brace transfers weight evenly across full floor plate to avoid point loading | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential formal dining room | Suitable for 8seat household dining layouts with light luxury interior design | |
|---|---|---|
| Apartment open-plan dining area | Fits combined living-dining spaces with modern minimal decorative styling | |
| Light commercial hospitality use | Appropriate for boutique hotel dining areas, high-end cafe private rooms | |
| Small meeting space | Usable for informal office meeting rooms requiring a wide flat work/dining surface | |
| Recommended pairing | Pairs with upholstered armless dining chairs with black metal legs and gold accent tips | |
| Suitable flooring types | Compatible with polished tile, marble, hardwood and luxury vinyl hard flooring surfaces |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 15187:2006 | Furniture assessment of surface resistance to dry heat, applicable for tabletop testing |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for hardware and structural safety checks | |
|---|---|---|
| GB 6566-2010 | Limit of radionuclides in building materials, applicable for sintered stone surface material testing | |
| GB/T 4893.9-2013 | Furniture surface test for heat resistance, applicable for tabletop performance verification |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for hardware and structural safety checks; 2. GB 6566-2010: Limit of radionuclides in building materials, applicable for sintered stone surface material testing; 3. GB/T 4893.9-2013: Furniture surface test for heat resistance, applicable for tabletop performance verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
