Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1500 x 1500 x 750 mm | |
|---|---|---|
| Central lazy Susan diameter | 900 mm | |
| Tabletop thickness | 12 mm | |
| Lazy Susan surface thickness | 8 mm | |
| Pedestal column width per section | 220 mm | |
| Base foot plate total spread diameter | 950 mm | |
| Seating clearance height under table apron | 680 mm | |
| Gold foot plate thickness | 5 mm | |
| Minimum chair clearance from pedestal base | 270 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Recommended seating capacity | 8 people | |
|---|---|---|
| Distributed static tabletop load capacity | 200 kg | |
| Net product weight | 95 kg | |
| Surface scratch resistance rating | 6 Mohs | |
| Surface heat resistance limit | 180 °C | |
| Lazy Susan rotational cycle rating | 30000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main tabletop | 12mm thick glossy white sintered stone with subtle marble veining | |
|---|---|---|
| Central lazy Susan tray | 8mm clear tempered glass with polished black edge trim | |
| Pedestal support columns | High-density MDF core with matte white UV-cured paint finish | |
| Base foot plates | 1.5mm thick 201 stainless steel with brushed gold PVD finish | |
| Lazy Susan rotating bearing | Zinc alloy silent ball bearing with nylon wear liner | |
| Tabletop support substrate | 15mm thick multi-layer plywood underlayment | |
| Fastener hardware | 304 stainless steel assembly bolts and connection brackets | |
| Base bottom protective pads | 5mm thick non-slip felt floor protection pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Central lazy Susan mechanism | 360-degree full rotation with silent ball bearing, no locking position | |
|---|---|---|
| Assembly configuration | Knock-down flat-pack construction with bolted pedestal to tabletop connection | |
| Surface maintenance feature | Non-porous sintered stone top resists oil and food stains, wipes clean with damp cloth | |
| Floor protection function | Felt pads under base foot plates prevent scratching hard stone or wood flooring | |
| Seating configuration | Circular open under-table layout supports 8 evenly spaced dining chairs | |
| Fixed height design | Non-adjustable 750mm working height optimized for standard 450mm seat height dining chairs | |
| Load distribution design | Three-point petal-shaped foot plate spreads weight evenly to prevent floor indentation | |
| Lazy Susan rotation axis height above floor | 760 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room application | Suitable for 8-seat family dining and casual guest entertaining in 25sqm dining spaces | |
|---|---|---|
| Open-plan living space application | Matches modern light-luxury and Italian minimalist interior decor schemes | |
| Small luxury apartment dining area | Pedestal base eliminates obstructive corner legs for flexible chair arrangement | |
| Recommended chair pairing | Coordinates with upholstered dining chairs with 460 mm seat height and gold metal legs | |
| Formal family meal use | Central lazy Susan supports shared dish service for family-style Chinese and Western dining |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to cold liquids |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to painted pedestal structure | |
|---|---|---|
| GB 6566-2010 | Limit of radionuclides in building materials, applicable to sintered stone tabletop | |
| GB/T 4893.4-2013 | Surface furniture film adhesion test method, applicable to painted pedestal finish |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to painted pedestal structure; 2. GB 6566-2010: Limit of radionuclides in building materials, applicable to sintered stone tabletop; 3. GB/T 4893.4-2013: Surface furniture film adhesion test method, applicable to painted pedestal finish; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
