Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1370 × 1370 × 760 mm | |
|---|---|---|
| Clear tempered glass top layer thickness | 10 mm | |
| Sintered stone-effect substrate thickness | 12 mm | |
| Metal edge trim width | 15 mm | |
| Pedestal base footprint | 650 x 650 mm | |
| Pedestal storage compartment internal height | 400 mm | |
| Individual extension leaf width | 108 mm | |
| Under-table leg clearance height | 680 mm | |
| Table edge overhang from pedestal | 360 mm | |
| Base metallic accent trim width | 20 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table net weight | 90 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 150 kg | |
| Maximum seated user capacity (extended) | 8 people | |
| Seated user capacity (closed round) | 6 people | |
| Glass surface impact resistance rating | 50 mm steel ball drop from 1000 mm without fracture | |
| Stone-effect top heat resistance | 180 °C direct contact without discoloration | |
| Extension rail slide cycle rating | 10000 open/close cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Top protective layer | 10mm clear tempered glass, polished smooth edge | |
|---|---|---|
| Tabletop substrate | 12mm grey sintered stone panel, natural marble pattern finish | |
| Table edge trim | 15mm wide polished stainless steel, brushed silver finish | |
| Pedestal main body | Painted MDF/engineered wood, matte light grey lacquer finish | |
| Pedestal accent trim | Polished stainless steel decorative ring, brushed gold-toned finish | |
| Pedestal storage door | Matte light grey engineered wood panel, fitted with metal pull handle | |
| Extension mechanism slides | Cold-rolled steel with soft-close damping coating | |
| Internal extension leaves | Honeycomb core engineered wood, matched grey stone-effect veneer | |
| Base foot pads | Non-slip PP plastic, adjustable height for floor leveling | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tabletop extension mechanism | 4-segment rotating slide system, converts round top to extended oval | |
|---|---|---|
| Extension leaf storage | Integrated internal storage within central pedestal compartment | |
| Pedestal storage access | Front-facing hinged door with metal pull handle, stores small dining items | |
| Tabletop surface protection | Tempered glass layer resists scratches, stains, and heat from tableware | |
| Soft-close extension action | Damped steel slides prevent sudden movement and reduce impact noise | |
| 360-degree unobstructed legroom | Central pedestal design eliminates corner legs blocking chair placement | |
| Adjustable floor leveling | Threaded foot pads compensate for uneven floor surfaces, eliminating table wobble | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room use | Suitable for 8person family meals and casual dining gatherings | |
|---|---|---|
| Open-plan living dining spaces | Modern light luxury aesthetic complements contemporary interior design schemes | |
| Small to medium apartment dining areas | Closed round configuration saves space, extends for guest use | |
| Show home and model apartment staging | Premium stone-glass finish creates high-end visual appeal for display use | |
| Recommended pairing | Matches modern upholstered dining chairs with black metal legs |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability, safety requirements for domestic dining tables | |
|---|---|---|
| EN 14073-2:2004 | Storage furniture safety requirements for pedestal compartment components |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to base structural performance | |
|---|---|---|
| GB 15763.2-2005 | Safety requirements for tempered glass used in furniture tops | |
| GB/T 4897.3-2015 | Performance requirements for particleboard used in furniture structural components |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to base structural performance; 2. GB 15763.2-2005: Safety requirements for tempered glass used in furniture tops; 3. GB/T 4897.3-2015: Performance requirements for particleboard used in furniture structural components; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
