PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1400 × 800 × 750 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Tabletop overhang on long sides | 50 mm | |
| Tabletop overhang on short ends | 70 mm | |
| Under-table knee clearance height | 690 mm | |
| Leg frame vertical section width | 80 mm | |
| Lower horizontal support bar height | 80 mm | |
| Floor contact footprint length | 1260 mm | |
| Floor contact footprint width | 700 mm | |
| Edge profile thickness (finished edge) | 50 mm | |
| Seating space per diner (long side) | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Net weight | 45 kg | |
|---|---|---|
| Distributed static tabletop load capacity | 150 kg | |
| Recommended seating capacity | 4 diners | |
| Surface heat resistance | 180 °C | |
| Surface scratch resistance | 6 Mohs | |
| Frame static load stability rating | 200 kg | |
| Adjustable foot adjustment range | 10 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface | Matte dark sintered stone | |
|---|---|---|
| Tabletop backing | Fiberglass-reinforced support board | |
| Frame material | Powder-coated carbon steel tubing | |
| Frame wall thickness | 1.5 mm | |
| Frame surface finish | Matte black electrostatic powder coating | |
| Leveling feet | Nylon-tipped threaded steel inserts | |
| Assembly hardware | Zinc-plated steel bolts and allen key | |
| Joint connectors | Welded steel corner gussets | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Table structure | Fixed non-extendable, non-foldable rigid assembly | |
|---|---|---|
| Leveling function | Threaded adjustable feet on each leg contact point | |
| Surface maintenance | Wipe-clean non-porous tabletop surface | |
| Leg clearance design | Open cantilever frame without central obstruction | |
| Assembly requirement | Knock-down flat-pack assembly with included hardware | |
| Surface use compatibility | Heat-resistant surface supports hot serving dishes directly | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room use | Suitable for small to medium apartment dining spaces | |
|---|---|---|
| Open-plan kitchen dining use | Matches modern minimalist interior design schemes | |
| Small cafe or break room use | Appropriate for light commercial casual dining settings | |
| Recommended pairing | Coordinates with upholstered dining chairs with black metal legs | |
| Surface use case | Supports daily meals, casual work, and small serving displays |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture safety requirement | EN 12521:2015 | |
|---|---|---|
| Surface scratch resistance | EN 15186:2012 | |
| Stability verification | EN 1730:2012 |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop dimensional tolerance | GB/T 3324 | |
|---|---|---|
| Surface coating adhesion | GB/T 4893.4 | |
| Frame structural stability | GB/T 10357.1 |
Standardized tender description text
This product must meet the following technical requirements: 1. Tabletop dimensional tolerance: GB/T 3324; 2. Surface coating adhesion: GB/T 4893.4; 3. Frame structural stability: GB/T 10357.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
