Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 900 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total product net weight | 85 kg | |
|---|---|---|
| Distributed tabletop static load capacity | 150 kg | |
| Seating capacity | 4 people | |
| Pedestal base stability rating | 120 kg horizontal side load | |
| Tabletop surface impact resistance | 10 J | |
| Surface scratch resistance (Mohs scale) | 6 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop substrate | 18mm MDF core with 2mm engineered stone veneer | |
|---|---|---|
| Tabletop finish | Matte white anti-scratch lacquer seal | |
| Pedestal columns | Solid MDF with vertical fluted routing | |
| Pedestal finish | Matte white powder-coated paint | |
| Internal support frame | 1.5mm thick steel connecting plate | |
| Base floor pads | 5mm thick non-slip rubber pads | |
| Adhesive bonding layer | High-strength structural epoxy | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Tabletop support structure | Triple fluted pedestal columns with no peripheral legs | |
|---|---|---|
| Assembly method | Knock-down construction with bolted tabletop-to-base connection | |
| Surface maintenance property | Non-porous sealed tabletop that resists common household liquid stains | |
| Seating layout compatibility | Supports chair placement on all four sides without leg obstruction | |
| Floor protection function | Rubber base pads prevent hard contact damage to smooth hard flooring | |
| Stability design | Three-column triangular base layout eliminates wobble on level floors | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining space | Suitable for 4-person apartment or small home dining areas | |
|---|---|---|
| Open-plan kitchen dining zone | Fits light-toned minimalist and contemporary kitchen interiors | |
| Small office breakout area | Appropriate for informal staff dining and meeting spaces | |
| Show home and staging installation | Ideal for modern residential staging to showcase minimalist aesthetic | |
| Compact apartment dining nook | Oval shape reduces corner collision risk in tight spaces |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
