Primary source
Contact the supplier for production scheduling and quotation.
PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1800 × 900 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Product net weight | 85 kg | |
| Recommended seating capacity | 6 people | |
| Tabletop impact resistance | 6 mm diameter steel ball 1m drop no crack | |
| Surface abrasion resistance | 4000 revolutions no visible wear | |
| Support base lateral stability load | 40 kg horizontal force at top edge no tipping | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 12mm polished sintered stone with subtle light grey marble veining | |
|---|---|---|
| Left support base | Dark grey matte coated cylindrical metal column | |
| Right support leg | 12mm thick smoked translucent acrylic panel with black metal frame | |
| Tabletop support frame | 20x40mm black powder-coated steel rectangular tubing | |
| Foot pads | Adjustable 10mm diameter nylon leveling feet | |
| Edge finish | Polished eased edge on sintered stone top | |
| Metal frame finish | Matte black electrostatic powder coating | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Leveling adjustment | 10mm vertical adjustment range on nylon foot pads | |
|---|---|---|
| Surface usability | Stain-resistant non-porous tabletop suitable for hot serving dishes up to 180°C | |
| Seating configuration | Accommodates 2 chairs on each long side and 1 chair on each short end | |
| Floor protection | Soft nylon foot pads prevent scratching of polished concrete, wood or tile floors | |
| Cleaning access | 1100mm open central clearance allows full legroom and easy floor cleaning under table | |
| Assembly method | Knock-down construction with bolted connection between top and support bases | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Fits open-plan modern minimalist dining areas for 6-person household meals | |
|---|---|---|
| Small open-plan kitchen dining zone | Suitable for apartment kitchen-diner spaces with mixed material interior palettes | |
| Show home display | Works as a styled centerpiece for modern residential show home staging | |
| Small boutique cafe seating | Suitable for premium casual cafe seating areas with contemporary aesthetic | |
| Studio apartment multi-use space | Functions as both dining table and casual work surface for home office use |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Domestic furniture safety | EN 12521:2015 | |
|---|---|---|
| Furniture surface assessment | EN 15186:2006 |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Dining table structural safety | GB/T 3324 | |
|---|---|---|
| Furniture mechanical stability | GB/T 10357.1 | |
| Furniture surface durability | GB/T 4893.1 |
Standardized tender description text
This product must meet the following technical requirements: 1. Dining table structural safety: GB/T 3324; 2. Furniture mechanical stability: GB/T 10357.1; 3. Furniture surface durability: GB/T 4893.1; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
