Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1600 x 900 x 750 mm | |
|---|---|---|
| Pedestal base floor contact length | 800 mm | |
| Pedestal base floor contact width | 600 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Static distributed tabletop load capacity | 159 kg | |
|---|---|---|
| Recommended seating capacity | 6 people | |
| Surface heat resistance | 180 °C | |
| Surface scratch resistance (Mohs hardness) | 6 | |
| Net product weight | 68 kg | |
| Tip-over resistance (static lateral load) | 30 kg | |
| Surface stain resistance rating | Class 5 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop core | 15mm thick sintered stone composite | |
|---|---|---|
| Tabletop finish | Matte nano-coating, low-glare non-porous surface | |
| Pedestal frame | 3mm thick A3 carbon steel tubing | |
| Base finish | Dark gray matte powder coating, scratch-resistant | |
| Floor contact pads | 8mm thick non-slip EVA rubber pads | |
| Mounting hardware | M8 zinc-plated steel bolts with lock washers | |
| Tabletop edge treatment | Precision CNC-machined rounded chamfer edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Seating layout accommodation | Supports 3 diners per long side, no end obstruction | |
|---|---|---|
| Surface use suitability | Resists hot dish contact, food spills, and daily cut scratches | |
| Cleaning maintenance | Wipe clean with damp soft cloth, no specialized cleaning agents required | |
| Stability performance | Central V-base eliminates table leg interference for chair positioning | |
| Assembly requirement | Knock-down assembly of tabletop to pre-built base unit | |
| Floor protection function | Soft EVA pads prevent scuffing and scratching on hard floor surfaces | |
| Adjustment features | Non-height-adjustable fixed dining height, no extendable leaves | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room application | Suitable for 6-person household dining areas in modern minimalist interiors | |
|---|---|---|
| Small open-plan kitchen dining use | Compact 1600mm footprint fits apartment kitchen-dining combined spaces | |
| Show home and model unit furnishing | Sleek designer silhouette suits display suites and residential staging projects | |
| Light commercial cafe seating | Durable stone top supports high-frequency daily use in small casual dining venues | |
| Recommended pairing | Coordinates with upholstered curved-back dining chairs with slim tapered legs |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety requirements for domestic dining tables | |
|---|---|---|
| EN 15372:2008 | Furniture - Surface resistance to cold liquids for hard furniture surfaces |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural stability inspection | |
|---|---|---|
| GB 18584-2001 | Indoor decoration material formaldehyde emission limit for furniture | |
| GB/T 4893.4-2013 | Surface film adhesion and abrasion resistance test for furniture surfaces |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural stability inspection; 2. GB 18584-2001: Indoor decoration material formaldehyde emission limit for furniture; 3. GB/T 4893.4-2013: Surface film adhesion and abrasion resistance test for furniture surfaces; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
