PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1200 × 1200 × 750 mm | |
|---|---|---|
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static load capacity | 150 kg | |
|---|---|---|
| Recommended seating capacity | 4 people | |
| Total product net weight | 42 kg | |
| Pedestal base floor bearing pressure | 0.02 MPa | |
| Surface scratch resistance rating | 3000 cycles | |
| Anti-tip stability factor | 1.8 | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop core material | 18mm thick high-density fiberboard substrate | |
|---|---|---|
| Tabletop surface finish | Matte white anti-fingerprint laminate coating | |
| Tabletop edge banding | Matching matte PVC edge banding | |
| Pedestal base structure | 1.5mm thick cold-rolled steel conical frame | |
| Pedestal base finish | Matte white electrostatic powder coating | |
| Floor protection ring | 3mm thick non-slip EVA rubber ring | |
| Tabletop-to-base connection | M10 carbon steel mounting bolts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Seating access design | Single central pedestal eliminates leg obstruction on all sides | |
|---|---|---|
| Floor protection function | Full perimeter EVA ring under base prevents hard contact with hard flooring | |
| Tabletop cleaning | Seamless non-porous matte surface allows wipe-down with standard household cleaners | |
| Assembly requirement | Knock-down construction requires attaching tabletop to pedestal base with included hardware | |
| Surface usage suitability | Flat level tabletop supports standard dining ware, place settings and small decorative items | |
| Stability performance | Wide 600mm diameter conical base prevents tipping when weight is applied to table edges | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining area use | Fits small to medium apartments and open-plan dining spaces as a 4-person dining table | |
|---|---|---|
| Casual meeting space use | Suitable for small office breakout areas or studio meeting nooks | |
| Small cafe or bistro use | Works for light commercial food service venues with 4seat table configurations | |
| Open-plan living room accent use | Serves as a statement accent table in minimalist or contemporary living spaces | |
| Recommended seating match | Pairs with armless dining chairs or low-back armchairs with seat height 450 mm |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
No standards data is available for this market.
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
No standards data is available for this market.
Standardized tender description text
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
