PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1500 × 1500 × 750 mm | |
|---|---|---|
| Central lazy susan diameter | 900 mm | |
| Tabletop thickness | 12 mm | |
| Lower stability plinth diameter | 800 mm | |
| Twisted metal support section width | 120 mm | |
| Knee clearance height under tabletop | 680 mm | |
| Table edge overhang from base plinth | 350 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Table static distributed load capacity | 250 kg | |
|---|---|---|
| Tabletop high temperature resistance | 1200 °C | |
| Seating capacity | 6 people | |
| Tabletop surface stain resistance rating | Grade 5 | |
| Base wall thickness | 2 mm | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test | |
| Recommended Procurement Warranty | Structure 5 years; hardware 3 years; finish 2 years |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main tabletop | 12mm glossy Pandora-pattern sintered stone, polished finish | |
|---|---|---|
| Central lazy susan | Matching 12mm glossy sintered stone, fitted with metal swivel bearing | |
| Twisted pedestal support | 2mm thick stainless steel with champagne gold PVD finish | |
| Lower stability plinth | Polished stainless steel with matching sintered stone inset | |
| Table edge treatment | Precision polished straight edge, 1mm radius chamfer | |
| Swivel bearing for lazy susan | Zinc-plated steel ball bearing race, 360-degree rotation | |
| Fastener hardware | 304 stainless steel bolts and connecting plates | |
| Surface coating on metal base | Electrophoretic primer + PVD champagne gold topcoat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy susan rotation | 360-degree smooth manual rotation via sealed ball bearing | |
|---|---|---|
| Lazy susan removability | Fully removable for cleaning or conversion to standard round table | |
| Pedestal base design | Single central twisted support eliminates corner leg obstructions | |
| Knock-down assembly | Tabletop, base, and plinth ship disassembled for reduced shipping volume | |
| Surface cleanability | Non-porous glossy surface wipes clean with damp cloth, no sealing required | |
| Leveling adjustment | Integrated adjustable feet on base plinth compensate for uneven floors | |
| Heat resistance | Tabletop withstands direct contact with hot pans up to 1200°C without damage | |
| Lazy susan rotation clearance from table edge | 300 mm | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Ideal for 6person family meals in open-plan or dedicated dining spaces | |
|---|---|---|
| Luxury apartment show homes | Suitable for model home staging to highlight modern upscale interior design | |
| Small private dining rooms | Appropriate for boutique restaurant private booths seating up to 6 guests | |
| Open-concept living spaces | Works in combined kitchen-dining areas with modern light-luxury interior schemes | |
| Recommended pairing | Pairs with armless upholstered dining chairs with champagne gold metal legs |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| Furniture mechanical safety standard | EN 12521:2015 | |
|---|---|---|
| Surface scratch resistance standard | EN 15186:2012 | |
| Furniture vertical load test standard | EN 1730:2012 |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| Tabletop stone panel standard | GB/T 35165 | |
|---|---|---|
| Metal furniture structural standard | GB/T 3324 | |
| Furniture surface paint film standard | GB/T 4893.4 | |
| Furniture stability test standard | GB/T 10357.7 |
Standardized tender description text
This product must meet the following technical requirements: 1. Tabletop stone panel standard: GB/T 35165; 2. Metal furniture structural standard: GB/T 3324; 3. Furniture surface paint film standard: GB/T 4893.4; 4. Furniture stability test standard: GB/T 10357.7; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
