PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 800 × 750 mm | |
|---|---|---|
| tabletop thickness | 12 mm | |
| leg section size | 50 x 50 mm square profile | |
| metal wall thickness | 1.2 mm | |
| cross brace height above floor | 120 mm | |
| undertable knee clearance height | 680 mm | |
| corner radius | 30 mm | |
| long side per-person seat width | 800 mm | |
| end side leg inset from edge | 100 mm | |
| adjustable glide adjustment range | 10 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| distributed static tabletop load | 113 kg | |
|---|---|---|
| tabletop surface heat resistance | 693 °C | |
| net product weight | 43 kg | |
| surface abrasion resistance | Class 4 | |
| frame rust resistance service life | 5 years | |
| seating capacity | 4 people | |
| limited residential warranty | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| tabletop substrate | 12mm high-pressure sintered stone, white base with grey-gold marble veining | |
|---|---|---|
| tabletop backing | 15mm MDF support panel | |
| frame and legs | Powder-coated dark gunmetal carbon steel | |
| horizontal cross braces | Same square carbon steel as legs, welded to vertical leg sections | |
| fasteners | M8 high-strength zinc-plated steel screws | |
| floor glides | Nylon non-marking adjustable glides | |
| finish coating thickness | 60 micron matte powder coat | |
| tabletop edge finish | Polished straight eased edge | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| floor leveling adjustment | 10mm height adjustment via nylon glides | |
|---|---|---|
| knock-down assembly | Assembly required with included hardware, no specialized tools needed | |
| surface cleanability | Non-porous surface resists stains, wipes clean with standard household cleaners | |
| impact safety design | Rounded 30mm corners reduce injury risk from sharp edges | |
| structural stability | Dual U-shaped leg frames with cross-bracing prevent wobble during use | |
| food contact suitability | Non-toxic non-porous surface safe for direct food placement | |
| scratch resistance | Hard sintered surface resists scratches from cutlery and tableware | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| residential dining room | Suitable for 4-person daily family meals, standard height compatible with dining chairs | |
|---|---|---|
| small open-plan kitchen | Compact 800mm depth fits narrow kitchen dining areas without blocking walkways | |
| apartment dining nook | 1600mm length fits standard 4-seat dining nooks in rental and condo units | |
| contemporary light luxury interiors | Marble-look sintered stone and dark metal frame matches modern minimalist and Italian-style decor | |
| home office secondary surface | Stable flat surface works as an overflow work table for laptops or paperwork in multi-use spaces | |
| casual meeting break areas | Durable easy-clean surface suitable for small office break rooms or studio common areas |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Safety, strength and durability requirements for domestic dining tables | |
|---|---|---|
| EN 15185:2011 | Furniture surface abrasion resistance test method for tabletops | |
| EN 1022:2018 | Domestic seating furniture stability test, applicable to paired dining set use |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to MDF backing panel | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture finishes, applicable to tabletop | |
| GB 18584-2001 | Limit of harmful substances in wooden furniture, applicable to backing panel |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to MDF backing panel; 2. GB/T 4893.4-2013: Surface abrasion resistance test for furniture finishes, applicable to tabletop; 3. GB 18584-2001: Limit of harmful substances in wooden furniture, applicable to backing panel; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
