PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1600 × 800 × 750 mm | |
|---|---|---|
| Overall assembled dimensions | 1600 x 800 x 750 mm | |
| Tabletop thickness | 18 mm | |
| Leg upper section diameter | 60 mm | |
| Leg lower section diameter | 30 mm | |
| Under-table knee clearance height | 720 mm | |
| Leg inset from table corners | 40 mm | |
| Table corner radius | 50 mm | |
| Long-side seating clearance per person | 530 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed tabletop static load capacity | 200 kg | |
|---|---|---|
| Leg static vertical load per leg | 60 kg | |
| Tabletop heat resistance (contact temperature) | 180 °C | |
| Surface abrasion resistance | 4 grade | |
| Product net weight | 48 kg | |
| Recommended seating capacity | 6 people | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop surface layer | 18mm matte white marble-veined sintered stone | |
|---|---|---|
| Tabletop backing panel | 15mm high-density particleboard support | |
| Leg structure | 1.5mm wall thickness carbon steel tubing | |
| Leg finish | Matte black epoxy powder coating | |
| Mounting hardware | M8 zinc-plated steel bolts with lock washers | |
| Edge finish | Hand-polished rounded stone edge, no sharp corners | |
| Foot pads | 8mm thick non-slip TPE adjustable floor glides | |
| Coating thickness on legs | 60 um | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Table structure type | Fixed non-extendable, non-folding rigid assembly | |
|---|---|---|
| Assembly method | Knock-down leg attachment to pre-drilled tabletop | |
| Floor protection | Adjustable TPE glides compensate for 10mm floor unevenness | |
| Surface cleaning suitability | Waterproof, stain-resistant surface wiped clean with damp cloth | |
| Under-table accessibility | Full open apron-free understructure for unobstructed leg movement | |
| Load distribution design | Four corner-mounted legs transfer weight directly to floor | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Tabletop shipping carton dimensions | 1700 x 900 x 150 mm | |
|---|---|---|
| Leg/hardware shipping carton dimensions | 800 x 600 x 200 mm | |
| Reference Package Count | 1 set / 2 cartons | |
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | Serves 6 people for daily family meals and casual gatherings | |
|---|---|---|
| Open-plan apartment living areas | Minimalist silhouette complements contemporary light luxury interiors | |
| Small commercial cafe seating areas | Durable sintered stone surface withstands high-frequency daily use | |
| Studio apartment dining zones | Compact 1.6m length fits limited open floor space without crowding | |
| Recommended paired seating | Upholstered armless dining chairs with 450mm seat height for ergonomic fit |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Test methods for table stability and vertical load performance |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for backing panel structural integrity | |
|---|---|---|
| GB/T 4893.1-2021 | Surface wear resistance test method, applicable for tabletop finish durability verification | |
| GB 28007-2011 | Furniture mechanical performance test for tables, applicable for static load stability verification |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for backing panel structural integrity; 2. GB/T 4893.1-2021: Surface wear resistance test method, applicable for tabletop finish durability verification; 3. GB 28007-2011: Furniture mechanical performance test for tables, applicable for static load stability verification; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
