| Submitted | Field | Original | Note / Status | |
|---|---|---|---|---|
No corrections yet. Use the flag at the end of a row to report an issue. | ||||
Automatic mm / inch conversion · Core engineering specifications
| Overall extended dimensions | 2000 x 920 x 786 mm | |
|---|---|---|
| Overall contracted dimensions | 1400 x 920 x 786 mm | |
| Tabletop thickness | 12 mm | |
| Central lazy Susan diameter | 800 mm | |
| Seating knee clearance height | 660 mm | |
| Table edge radius | 60 mm | |
| Plinth base height | 126 mm | |
| Extension leaf length per side | 300 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load capacity | 204 kg | |
|---|---|---|
| Recommended maximum seating capacity | 8 persons | |
| Tabletop surface heat resistance | 180 °C | |
| Tabletop surface scratch resistance (Mohs hardness) | 6 grade | |
| Product net weight | 100 kg | |
| Extension rail sliding cycle rating | 10000 cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Main tabletop surface | 12mm polished sintered stone with white marble-vein finish | |
|---|---|---|
| Central lazy Susan tray | 10mm polished sintered stone matching tabletop pattern, mounted on rotating bearing | |
| Plinth base exterior | Matte dark brown/black engineered wood finish with anti-scratch coating | |
| Internal support frame | 1.5mm thick carbon steel square tubing reinforcement inside plinth | |
| Extension sliding rails | Cold-rolled steel rails with nylon silent sliders | |
| Lazy Susan rotating bearing | Zinc alloy 360-degree silent swivel bearing | |
| Table edge treatment | Hand-polished rounded bevel edge with no sharp corners | |
| Base floor contact pads | Non-slip rubber pads to prevent floor scratching | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Table extension mechanism | Dual-side pull-out extension leaves with self-locking steel rails, no additional tools required to extend or retract | |
|---|---|---|
| Central lazy Susan function | 360-degree smooth silent rotation for shared dish access during meals | |
| Seating flexibility | Seats 6people in contracted position, 8 people in fully extended position | |
| Surface maintenance | Non-porous sintered stone surface resists oil and stain penetration, wipes clean with damp cloth | |
| Base stability design | Wide solid plinth base eliminates wobble even when table is fully extended | |
| Extension safety feature | Built-in leaf locking mechanism prevents accidental sliding during use | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room use | Ideal for open-plan home dining areas hosting family meals and small gatherings, fits 8-seat configuration | |
|---|---|---|
| Small restaurant or private dining room use | Suitable for boutique cafes or private restaurant dining spaces needing flexible seating capacity | |
| Modern minimalist interior schemes | Matches contemporary, light-luxury, and minimalist decor styles with neutral stone finish and dark base | |
| Open-concept living-dining spaces | Low-profile plinth base and rounded edges work well in open floor plans without visual obstruction | |
| Recommended pairing | Pairs with upholstered dining chairs with metal legs for a coordinated modern dining set |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables, applicable for performance verification | |
|---|---|---|
| EN 13722:2004 | Furniture - Test methods for surface resistance to abrasion for table tops | |
| EN 71-3:2019+A1:2021 | Safety of toys - Migration of certain elements, applicable for surface finish safety for household use |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to base structure quality verification | |
|---|---|---|
| GB/T 4897.3-2015 | Particleboard for furniture use, applicable if plinth uses wood-based panel core | |
| GB 18584-2001 | Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to base structure quality verification; 2. GB/T 4897.3-2015: Particleboard for furniture use, applicable if plinth uses wood-based panel core; 3. GB 18584-2001: Indoor decorating and refurbishing materials - limit of harmful substances for wooden furniture; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
