Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions (extended) | 2200 x 900 x 760 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Pedestal base footprint per unit | 450 x 450 mm | |
| Under-table knee clearance height | 700 mm | |
| Extension leaf width | 400 mm | |
| Rounded end radius | 150 mm | |
| Gold trim base ring diameter | 480 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Distributed tabletop static load | 150 kg | |
|---|---|---|
| Seating capacity (closed) | 6 seats | |
| Seating capacity (extended) | 8 seats | |
| Surface heat resistance | 120 °C | |
| Surface scratch resistance rating | 3 Grade | |
| Table unit net weight | 90 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop substrate | Polished blue-grey natural marble/sintered stone | |
|---|---|---|
| Tabletop edge treatment | Smooth polished eased edge | |
| Pedestal base structure | 1.2mm thick powder-coated dark grey carbon steel | |
| Base decorative trim | Gold-toned plated stainless steel accent rings | |
| Internal support frame | Powder-coated steel inner support frame | |
| Extension mechanism hardware | Zinc-plated steel sliding rail system | |
| Foot pads | Adjustable non-slip plastic foot glides | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
Adjustment / rotation / tilt / mobility / storage features
| Extension mechanism type | Hidden butterfly leaf extension system | |
|---|---|---|
| Extension operation | Dual pedestal sliding action | |
| Length adjustment positions | 2 positions | |
| Level adjustment | 10mm adjustable foot pad travel | |
| Surface maintenance | Non-porous polished stone finish | |
| Load distribution | Dual pedestal weight distribution | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room | Serves 8diners for daily meals and formal family gatherings | |
|---|---|---|
| Open-plan kitchen dining area | Coordinates with modern light-luxury interior design schemes | |
| Hotel private dining suite | Durable stone surface withstands frequent commercial hospitality use | |
| Apartment model home furnishing | Visual focal point for staged real estate showrooms | |
| Small event banquet space | Extendable length adapts to small private event seating needs |
EU Market Access Requirements* EN Standards
| Domestic furniture safety | EN 12521:2015 | |
|---|---|---|
| Stone surface performance | EN 14617:2016 | |
| Furniture stability testing | EN 1022:2018 |
Standards applicable to China-market projects
| Stone dining table top safety | GB 6566 | |
|---|---|---|
| Furniture structural safety | GB/T 3324 | |
| Furniture surface durability | GB/T 4893.4 |
This product must meet the following technical requirements: 1. Stone dining table top safety: GB 6566; 2. Furniture structural safety: GB/T 3324; 3. Furniture surface durability: GB/T 4893.4; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
