PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 2000 × 1000 × 770 mm | |
|---|---|---|
| Tabletop thickness | 20 mm | |
| Leg section size | 60 x 60 mm | |
| Leg wall thickness | 2 mm | |
| Under-table knee clearance height | 680 mm | |
| Under-table knee clearance depth | 940 mm | |
| Tabletop corner radius | 5 mm | |
| Leg inset from tabletop edge | 50 mm | |
| Adjustable foot pad height | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Total static distributed load capacity | 300 kg | |
|---|---|---|
| Surface temperature resistance | 1200 °C | |
| Surface Mohs hardness | 6 | |
| Seating capacity | 6 people | |
| Surface water absorption rate | 0.02% | |
| Net weight reference | 85 kg | |
| Powder coat finish durability | 1000 abrasion cycles | |
| Manufacturer warranty period | 1 year | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop panel | AAA-grade matte white sintered stone | |
|---|---|---|
| Leg structure | Powder-coated black carbon steel | |
| Leg internal support | Reinforced welded steel cross bracing | |
| Tabletop mounting hardware | M8 zinc-plated steel screws | |
| Foot pads | Non-slip TPE adjustable glides | |
| Tabletop edge finish | Seamless polished sintered stone edge | |
| Surface finish layer | Nano anti-fingerprint matte coating | |
| Anti-rust treatment for legs | Electroplated base under powder coat | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Structural configuration | Fixed non-extendable rectangular top | |
|---|---|---|
| Level adjustment | Rotatable TPE foot pads adjust 15mm for uneven floors | |
| Assembly requirement | Leg attachment to pre-drilled tabletop frame | |
| Surface cleanability | Non-porous surface wipes clean without sealant | |
| Floor protection | Soft TPE glides prevent hard floor scratches | |
| Seating access | Full open clearance on all four sides | |
| Edge safety | Rounded 5mm radius corners reduce impact injury | |
| Stability performance | Welded leg joints eliminate wobble at maximum load | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Seats 6 for family meals and casual gatherings | |
|---|---|---|
| Open-plan kitchen diner | Minimalist silhouette complements modern neutral interiors | |
| Small apartment open living area | Compact 1000mm depth saves floor space while seating 6 | |
| Commercial cafe private dining booth | Durable sintered stone surface withstands high daily use | |
| Recommended pairing | 6 slim-profile upholstered dining chairs (450mm seat height) | |
| Surface use suitability | Supports hot serveware, dining ware, and small decorative objects |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Applies to domestic dining table strength, durability and safety requirements | |
|---|---|---|
| EN 15187:2006 | Applies to furniture surface resistance to cold liquid staining |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
No standards data is available for this market.
Standardized tender description text
This product must meet the following technical requirements: 1. Technical standards and test reports must be supplied during tender or purchase confirmation; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
