Automatic mm / inch conversion · Core engineering specifications
| Overall dimensions | 1800 x 900 x 750 mm | |
|---|---|---|
| Tabletop thickness | 12 mm | |
| Tabletop overhang per side | 50 mm | |
| Under-table knee clearance height | 700 mm | |
| Knee clearance width along long edge | 1600 mm | |
| Knee clearance depth along short edge | 750 mm | |
| Base floor plate dimensions | 1200 x 700 x 20 mm | |
| Pedestal minimum leg clearance height | 150 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Net weight / load capacity / users / durability
| Table total net weight | 115 kg | |
|---|---|---|
| Evenly distributed static tabletop load | 150 kg | |
| Recommended seating capacity | 6 diners | |
| Tabletop surface heat resistance | 180 °C | |
| Tabletop scratch resistance rating | 6 Mohs | |
| Base finish salt spray resistance | 48 hours | |
| Recommended residential warranty period | 3 years | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles |
Core acceptance fields · Panels / hardware / frame / upholstery
| Tabletop surface material | 12mm glossy white sintered stone | |
|---|---|---|
| Tabletop edge finish | Polished softly rounded edge | |
| Tabletop backing panel | 15mm MDF reinforcing substrate | |
| Pedestal support structure | 2mm thick champagne finish carbon steel | |
| Floor stabilizing plate | 3mm thick rectangular flat carbon steel plate | |
| Metal surface coating | Electrostatic powder coating with champagne metallic finish | |
| Floor contact pads | 8mm thick non-slip rubber glides | |
| Assembly hardware | M10 zinc-plated steel connecting bolts | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Adjustment / rotation / tilt / mobility / storage features
| Seating access configuration | Perimeter seating on all four sides with central pedestal support | |
|---|---|---|
| Surface cleaning function | Non-porous stain-resistant smooth top surface | |
| Floor level adjustment | M10 adjustable glides at floor plate corners | |
| Assembly configuration | Two-part knock-down construction for transport | |
| Edge protection design | Rounded eased tabletop edges | |
| Stability design feature | Wide rectangular low-profile base plate | |
| Available finish variants | 3 base finish options, 2 top finish options | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Verified carton / gross weight / assembly / loading data
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Recommended spaces / users / usage modes
| Residential dining room use | Suitable for 6person family dining in open-plan or dedicated dining spaces | |
|---|---|---|
| Open-plan living space application | Fits contemporary light luxury, modern minimalist interior design schemes | |
| Small apartment dining area use | Compact central pedestal design maximizes leg room without leg obstructions | |
| Show home/model home furnishing | Ideal for display in residential development model suites | |
| Matching furniture recommendation | Pairs with armless upholstered dining chairs with tapered metallic legs | |
| Floor surface compatibility | Suitable for wood, tile, vinyl and stone flooring with fitted rubber glides |
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables, applicable for structural performance verification | |
|---|---|---|
| EN 14749:2016 | Domestic and kitchen storage units/worktops safety requirements, applicable to tabletop surface performance | |
| EN 10346:2015 | Continuously hot-dip coated steel flat products, applicable to metal base material quality verification |
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable to structural stability and finish quality checks | |
|---|---|---|
| GB/T 4897.3-2017 | Particleboard for furniture use, applicable if MDF/wood composite backing is used in tabletop assembly | |
| GB 6566-2010 | Radionuclide limits for building decoration materials, applicable to sintered stone/ceramic tabletop material safety |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable to structural stability and finish quality checks; 2. GB/T 4897.3-2017: Particleboard for furniture use, applicable if MDF/wood composite backing is used in tabletop assembly; 3. GB 6566-2010: Radionuclide limits for building decoration materials, applicable to sintered stone/ceramic tabletop material safety; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
