PRODUCT MODULE 01 / 06
Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 760 mm | |
|---|---|---|
| Lazy susan diameter | 800 mm | |
| Tabletop thickness | 12 mm | |
| Floor base diameter | 700 mm | |
| Undertable knee clearance height | 690 mm | |
| Edge radius | 15 mm | |
| Pedestal X-support width at top | 120 mm | |
| Lazy susan edge trim width | 20 mm | |
| Mounting plate thickness | 15 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
PRODUCT MODULE 02 / 06
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Recommended seating capacity | 6 people | |
|---|---|---|
| Distributed static load capacity | 150 kg | |
| Tabletop heat resistance | 1200 °C | |
| Surface scratch resistance (Mohs hardness) | 7 | |
| Net weight | 100 kg | |
| Base stability lateral load rating | 40 kg | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
PRODUCT MODULE 03 / 06
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main tabletop | 12mm glossy white sintered stone, food-grade non-porous surface | |
|---|---|---|
| Lazy susan turntable | Matching 12mm white sintered stone with dark PVC edge trim | |
| Pedestal support frame | 1.8mm thick carbon steel with champagne rose gold PVD finish | |
| Floor stabilizing base | 2.0mm thick carbon steel with matching champagne finish, non-slip EVA foot pads | |
| Turntable swivel bearing | Zinc alloy silent ball bearing, 360° rotation | |
| Tabletop mounting substrate | 15mm thick multi-layer plywood board, E0 grade | |
| Surface finish coating on base | Epoxy primer + PVD titanium gold coating, rust-resistant | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support | |
| Reference Finish / Color Count | Recommended 6top finishes and 3frame colors |
PRODUCT MODULE 04 / 06
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy susan rotation | 360° silent bidirectional rotation with zero stopping positions | |
|---|---|---|
| Turntable removability | Fully removable for cleaning or use as standard non-turntable dining table | |
| Edge safety design | Fully rounded polished edges with no sharp corners | |
| Legroom design | Full unobstructed perimeter leg space with no corner legs | |
| Surface cleanability | Non-porous wipe-clean surface resistant to oil, stains and common household chemicals | |
| Floor protection | 4 hidden non-slip EVA pads under the circular base | |
| Assembly requirement | Three-point bolted connection between base, support and tabletop | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
PRODUCT MODULE 05 / 06
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
PRODUCT MODULE 06 / 06
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Ideal for 6person family meals and casual gatherings, modern luxury aesthetic | |
|---|---|---|
| Apartment open-plan dining area | Compact central pedestal design maximizes legroom without protruding legs | |
| Small private restaurant dining booth | Durable easy-clean surface suitable for moderate commercial food service use | |
| Luxury show home dining display | Coordinated champagne and white finish matches contemporary interior design schemes | |
| Recommended pairing | Matches armless upholstered dining chairs with black metal legs as shown in product imagery |
STANDARD S1
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture – Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 13722:2004 | Furniture – Test methods for surface resistance to dry and wet heat | |
| EN 15187:2006 | Furniture – Test method for surface resistance to mechanical scratch damage |
STANDARD S3
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden furniture, applicable for plywood mounting components | |
|---|---|---|
| GB/T 4893.4-2013 | Surface abrasion resistance test for furniture finishes, applicable for tabletop coating verification | |
| GB 18580-2017 | Formaldehyde emission limit for wood-based panels, applicable for plywood substrate | |
| GB/T 24821-2009 | General requirements for dining tables and chairs, applicable for structural stability testing |
Standardized tender description text
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden furniture, applicable for plywood mounting components; 2. GB/T 4893.4-2013: Surface abrasion resistance test for furniture finishes, applicable for tabletop coating verification; 3. GB 18580-2017: Formaldehyde emission limit for wood-based panels, applicable for plywood substrate; 4. GB/T 24821-2009: General requirements for dining tables and chairs, applicable for structural stability testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
