Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 750 mm | |
|---|---|---|
| Tabletop thickness | 10 mm | |
| Lazy Susan diameter | 900 mm | |
| Pedestal column diameter | 400 mm | |
| Pedestal column height | 700 mm | |
| Gold base plinth diameter | 600 mm | |
| Gold base plinth height | 50 mm | |
| Undertable knee clearance height | 700 mm | |
| Lazy Susan thickness | 12 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Tabletop static distributed load capacity | 150 kg | |
|---|---|---|
| Tabletop temperature resistance range | -20°C to 150°C | |
| Recommended seating capacity | 4 people | |
| Product net weight | 85 kg | |
| Surface scratch resistance | Level 3 (4H pencil hardness) | |
| Turntable rotation lifespan | 30000 rotation cycles | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Tabletop | 10mm clear tempered glass with polished rounded edge | |
|---|---|---|
| Central lazy Susan | 12mm black tempered glass with smooth rotating bearing | |
| Pedestal column | MDF core with matte white paint, vertical fluted texture | |
| Base plinth | 1.2mm thick gold-finish polished stainless steel | |
| Turntable bearing | Zinc-plated steel ball bearing assembly | |
| Hardware connectors | 304 stainless steel assembly bolts and brackets | |
| Surface coating | Polyurethane matte paint on pedestal, 20μm dry film thickness | |
| Base foot pads | 5mm thick non-slip rubber pads | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Lazy Susan rotation | 360-degree full manual rotation, no lock positions, removable for cleaning | |
|---|---|---|
| Seating access | 360-degree unobstructed access around single central pedestal | |
| Surface cleaning | Smooth non-porous glass surfaces wipe clean with standard household cleaners | |
| Floor protection | Rubber foot pads prevent scratches on hard flooring and carpets | |
| Assembly design | Three-part knockdown assembly (top, column, base) with bolted connections | |
| Load distribution | Wide metal plinth spreads weight evenly to prevent floor indentation | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining rooms | Seats 4 people comfortably for daily family meals and casual gatherings | |
|---|---|---|
| Open-plan living areas | Pedestal design offers legroom and unobstructed sightlines for open layouts | |
| Small restaurant private dining rooms | Durable glass surface supports commercial light-use dining applications | |
| Modern luxury interiors | White fluted pedestal and gold hardware complement contemporary light-luxury decor | |
| Apartment dining nooks | 1350mm diameter fits compact dining areas without overwhelming space |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Applies to strength, durability and safety requirements for domestic dining tables | |
|---|---|---|
| EN 14073-2:2004 | Applies to storage and office furniture surface stability | |
| EN 12150-1:2015 | Applies to thermally toughened soda lime silicate safety glass |
North America Purchasing & Inspection Reference * ANSI/BIFMA Standards
US and Canada office-furniture standards
| ANSI/BIFMA X5.5-2021 | Applies to desk and table performance testing for commercial applications | |
|---|---|---|
| ANSI/BIFMA X5.1-2017 | Applies to general furniture safety and structural integrity |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | Applies to general technical requirements for wooden dining furniture | |
|---|---|---|
| GB 15763.2-2005 | Applies to safety requirements for tempered glass furniture surfaces | |
| GB/T 4893.9-2013 | Applies to furniture surface heat resistance testing |
This product must meet the following technical requirements: 1. GB/T 3324-2017: Applies to general technical requirements for wooden dining furniture; 2. GB 15763.2-2005: Applies to safety requirements for tempered glass furniture surfaces; 3. GB/T 4893.9-2013: Applies to furniture surface heat resistance testing; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
