Physical Dimensions
Automatic mm / inch conversion · Core engineering specifications
Data source: Structured from factory data; final measured values prevail.
| Overall dimensions (W × D × H) | 1350 × 1350 × 770 mm | |
|---|---|---|
| Central lazy susan diameter | 800 mm | |
| Sintered stone tabletop thickness | 12 mm | |
| Lower circular support foot diameter | 650 mm | |
| X-frame metal leg section width | 80 mm | |
| X-frame metal leg wall thickness | 2 mm | |
| Undertable knee clearance height | 680 mm | |
| Table edge overhang from base outer edge | 350 mm | |
| Finished Top Thickness | 45 mm | |
| Effective Knee Clearance | 680 mm high and 900 mm wide per main seat | |
| Leg / Support Section | 80 mm main section with 2 mm metal wall | |
| Cable Opening Size | 80 mm diameter; cable tray depth 120 mm |
Weight, Load & Performance
Net weight / load capacity / users / durability
Data source: Product performance data; verify exact test conditions before procurement.
| Distributed static tabletop load capacity | 150 kg | |
|---|---|---|
| Net table weight | 85 kg | |
| Recommended seating capacity | 4 persons | |
| Lazy susan rotation endurance | 30000 cycles | |
| Surface heat resistance | 180 °C | |
| Surface scratch resistance rating | 6 Mohs | |
| Top Static Load Reference | 150 kg uniformly distributed | |
| Drawer Slide Load / Life | 45 kg/pair; 50000 cycles | |
| Hinge Opening Life | Acceptance target 80000 cycles | |
| Top Abrasion Reference | Acceptance target ≥4,000 abrasion cycles or finish-system test |
Materials & Structure
Core acceptance fields · Panels / hardware / frame / upholstery
Data source: Subject to the factory material list and inspection report.
| Main tabletop | 12mm thick marble-vein sintered stone, polished finish | |
|---|---|---|
| Central lazy susan turntable | Matching sintered stone surface, stainless steel rotary bearing | |
| X-shape support frame | Brushed champagne gold carbon steel, welded cross structure | |
| Lower circular foot plate | Matching marble-vein sintered stone, fixed to frame bottom | |
| Frame connecting hardware | Zinc-plated steel bolts and lock nuts, M8 size | |
| Turntable rotary bearing | Stainless steel ball bearing, 360-degree rotation | |
| Table edge treatment | Smooth polished beveled edge, 1mm radius | |
| Metal frame surface finish | Electroplated brushed metallic coating, anti-scratch clear seal | |
| Primary Panel Thickness | 25 mm; load-bearing top may use 40 mm composite build-up | |
| Edge Band Thickness | 2 mm | |
| Metal Frame Wall Thickness | 2 mm cold-rolled steel | |
| Primary Connector Specification | Reference M6-M8 with at least 2 fixing points per main support |
Functions & Adjustment
Adjustment / rotation / tilt / mobility / storage features
Data source: Functional configuration; the supplier specification prevails.
| Central lazy susan operation | 360-degree full rotation, smooth ball bearing movement, non-removable fixed assembly | |
|---|---|---|
| Base structural support | X-cross frame distributes load evenly to circular foot, prevents wobble on flat floors | |
| Tabletop surface function | Stain-resistant, easy wipe-clean, scratch and heat resistant for daily dining use | |
| Knockdown assembly | Flat-packed for transport, requires bolted assembly of base to tabletop | |
| Surface use compatibility | Supports direct placement of hot cookware, plates, serving dishes without surface damage | |
| Dining serving function | Rotating turntable allows all seated diners to access shared dishes without reaching across table | |
| Cable Management Capacity | Reference capacity 10power/data cables; tray load 10 kg | |
| Reference Reassembly Count | Main joints should support 5controlled assembly cycles |
Packaging & Logistics
Verified carton / gross weight / assembly / loading data
Data source: Reference for export quotations and container planning.
| Reference Package Count | 1 set / 2 cartons | |
|---|---|---|
| Reference Assembly Time | 40 minutes per set | |
| Reference Package Dimensions | 2100× 1100× 300 mm | |
| Reference Packaged Gross Weight | 90 kg/set in 2 cartons | |
| Reference Packaging Volume | 0.55 m³/set |
Applications & Usage
Recommended spaces / users / usage modes
Data source: Recommended applications based on product form and category.
| Residential dining room | Ideal for 4-person family meals in apartments or small homes of 90sqm and above | |
|---|---|---|
| Small apartment open-plan dining area | Compact round shape saves space, no sharp corners for safe family use | |
| Light luxury style interior | Matches modern minimalist, contemporary, and light luxury home decor schemes | |
| Small commercial cafe private dining room | Suitable for 4-guest dining booths in boutique restaurants or tea houses | |
| Combined dining set configuration | Pairs with matching upholstered dining chairs with metal legs for coordinated furniture sets |
EU Market Entry Requirements * EN Standards
EU Market Access Requirements* EN Standards
| EN 12521:2015 | Furniture - Strength, durability and safety for domestic dining tables | |
|---|---|---|
| EN 14073-2:2004 | Office and domestic storage furniture surface durability, referenced for dining top wear | |
| EN 1730:2012 | Test methods for domestic tables, stability and static load testing |
Standards Applicable to China-Market Projects * GB Standards
Standards applicable to China-market projects
| GB/T 3324-2017 | General technical requirements for wooden and stone household dining tables | |
|---|---|---|
| GB/T 4100-2015 | Ceramic tile / sintered stone surface quality and physical performance standards | |
| GB/T 4893.9-2013 | Furniture surface test for heat resistance |
This product must meet the following technical requirements: 1. GB/T 3324-2017: General technical requirements for wooden and stone household dining tables; 2. GB/T 4100-2015: Ceramic tile / sintered stone surface quality and physical performance standards; 3. GB/T 4893.9-2013: Furniture surface test for heat resistance; Final delivery parameters, test reports, and acceptance criteria are subject to the purchase contract.
